Common Services
Service code
5. Class 0x05 Connection
Class attributes
Instance 1: Master/Slave Explicit Message Connection
Instance 2: Polled I/O Connection
DVP-PLC Application Manual
DeviceNet Slave Communication Module IFD9502
Attribute ID Access rule
3 Get/Set
4 Get/Set
5 Get
6 Get
7 Get
8 Get
9 Get
Implemented for
Class
0x0E Yes
0x10 No
0x4B No
0x4C No
Attribute ID Access rule
1 Get
Attribute ID Access rule
1 Get
2 Get
3 Get
4 Get
5 Get
6 Get
7 Get
8 Get
9 Get/Set
12 Get/Set
13 Get
14 Get
15 Get
16 Get
Name
BusofInterrupt
BusofCounter
AllocationInfo
AllocationChioce
MasterNodeAddress
MACIDSwitchChanged
BaudRateSwitchChanged
MACIDSwitchValue
BaudRateSwitchValue
Instance
Yes Get_Attribute_Single
Yes Set_Attribute_Single
Yes Allocate_Master/Slave_Connection_Set
Yes Release_Master/Slave_Connection_Set
Name
Revision
Name
State
InstanceType
TransportClassTrigger
ProducedConnectionId
ConsumedConnectionId
InitialCommCharacteristics
ProducedConnectionSize
ConsumedConnectionSize
ExpectedPackedRate
WatchdogTimeoutAction
Produced Connection Path Length
Produced Connection Path
Consumed Connection Path Length
Consumed Connection Path
Data type
BOOL
USINT
BYTE
USINT
BOOL
BOOL
USINT
USINT
Service name
Data type
UINT
Data type
USINT
USINT
USINT
UINT
UINT
BYTE
UINT
UINT
UINT
USINT
USINT
EPATH
USINT
EPATH
