DeviceNet Slave Communication Module IFD9502
Format of messages responded
Byte position
0
1
2
3
Note
When modifying parameters in the parameter table of the device, make sure that the parameter allows
you to modify it before you modify it.
4. I/O data mapping (Default)
AC motor drive → DeviceNet master
Node address of
AC motor drive
H'2101
H'2102
DeviceNet master → AC motor drive
Node address of
AC motor drive
H'2000
H'2001
Explanation
When the equipment connected to IFD9502 is an AC motor drive, the length of data downloaded
from IFD9502 to the AC motor drive is preset as 2 words at addresses H'2000 and H'2001.
IFD9502 is able to download maximum 8 words to AC motor drive. The length of data uploaded
to IFD9502 from AC motor drive is preset as 2 words at addresses H'2101 and H'2102 and
IFD9502 is able to be uploaded maximum 8 words.
The length of data transmitted from IFD9502 to the AC motor drive is preset as 2 words. If you
need to extend the length, you have to first set up Class 0x95>>Instance1>>Attribute2 as the
destination value and next set up Attribute11 ~ Attribute 18. The length of data transmitted from
the AC motor drive to IFD9502 is preset as 2 words. If you need to extend the length, you have to
first set up Class 0x95>>Instance1>>Attribute3 as the destination value and next set up
Attribute25 ~ Attribute32.
Length of I/O data to be exchanged and address for I/O mapping can be modified through
changing Class 0x95 as listed below. The modification will be valid after IFD9502 is re-powered.
Maximum 16 words are allowed for I/O data exchange.
If you are to return the I/O mapping to default setting, change Attribute1 of Instance1 of Class
0x95 into H'0001 and re-power IFD9502. Please note that doing so can only recover the current
I/O data mapping in the AC motor drive.
Class 0x95 Data Config
Instance0:
8
Data written into AC motor drive
Frag [0]+XID+MAC ID
R/R [1]+Service code [0x10]
N/A
N/A
b15 b14 b13 b12 b11 b10 b9
- Status of command control
Displaying frequency command
b15 b14 b13 b12 b11 b10 b9
Control command of AC motor drive
Frequency command of AC motor drive
Data read from AC motor drive
Frag [0]+XID+MAC ID
R/R [1]+Service code [0x0E]
Response data LSB
Response data MSB
b8 b7 b6 b5 b4 b3
LED status of AC motor
-
b8 b7 b6 b5 b4 b3
DVP-PLC Application Manual
b2 b1 b0
drive
b2 b1 b0
