SpectraLink IP-DECT Server 400 Deployment Manual page 29

Synchronization and Deployment Guide
Default sync type
LAN sync transport protocol
Base Station Individual Settings
Type
Base Station Synchronization Status
The synchronization status is displayed on the Administration -> Base Stations page of the web
GUI. The Sync column displays a green icon for base stations that are currently running as slaves
and a blue one for the current master.
14169000 Version 9.3
October, 2016
This setting controls the default synchronization type for
new base stations. The following values can be
selected:
•
Free running
•
Radio (default)
•
LAN
This setting controls the protocol used as transport for
the PTPv2 packets used for synchronization. The
following values can be selected:
•
Ethernet
•
IPv4 (default)
•
IPv6
IPv4 is the default and recommended in most networks.
This setting controls the synchronization type for
specific base station. The following values can be
selected:
•
Free running
•
Radio
•
LAN
•
Gateway
29
