5. Remove the two front panel screws on the right side of the library (Figure 7).
6. Remove the two front panel screws on the left side of the library (Figure 8).
7. Pull the front panel gently away from the library.
10
Spectra 10000 Front Panel Replacement Guide
Remove Front Panel
Figure 7 Remove the right side
front panel screws.
Figure 8 Remove left side front panel
screws.
