Table 18: Modbus accessories ordering information
Product Code Number
IU-9100-8401 (Europe)
IU-9100-8404 (Europe) or
BM485-CIP (North America)
Table 19: M-Bus accessories ordering information
Product Code Number
SIS-MBUSSCSL-0E
SIS-MBUSSCLL-0E
SIS-MBUSNCLL-0E
SIS-MBUSNCLH-0E
SIS-MBUSRPLL-0E
SIS-MBUSRPLH-0E
INT-DX-KAB01
Note: Order these accessories in AOMS from the Essen Distribution Center.
Table 20: KNX accessories ordering information
Product Code Number
SIS-KNXNIXL-0E
SIS-KNXNRXL-0E
Note: Order this accessory in AOMS from the Essen Distribution Center.
Table 21: Modbus training tool ordering information
Course number
C-10077-EN
PTK-CONT-26
Note: Modbus Integrations require one or more vendor Modbus definition (VMD) tables for specific
third-party equipment. You can purchase tables from your regional System Integration Services (SIS)
office, or you can create the tables with the VMD Generator Express (VGE) tool. To obtain a license,
attend the training listed in this table.

Technical specifications

Description
RS232-to-RS485 converter, 230 VAC
Order this accessory in AOMS from the Essen Distribution Center.
RS232-to-RS485 converter, 24 VAC
For the European market, order this accessory in AOMS from the Essen
Distribution Center. For the North American market, order this accessory from
duTec (http://www.interfaceconverter.com or 1-800-248-1632), specify vendor
#290904
Description
M-Bus level converter for up to 6 unit loads, 24V AC/DC (RS-232 connection)
M-Bus level converter for up to 100 unit loads, 24V AC/DC (RS-232 connection)
M-Bus level converter for up to 100 unit loads; 24 VAC/VDC (IP connection)
M-Bus level converter for up to 100 unit loads; 230 VAC (IP connection)
M-Bus repeater for up to 100 unit loads, 24V AC/DC
M-Bus repeater for up to 100 unit loads; 230 VAC
Optional connection cable SUB-D to RJ-12 for use with SIS-MBUSSCLL-0E
Description
KNX IP interface module to connect KNX line through Ethernet to a network
engine
KNX IP router to connect KNX line through Ethernet to a network engine,
including line or area coupler functionality
Course title and description
VGE Tool Software Training (North America)
The VGE tool is required to generate custom Modbus mapping tables.
VGE Tool Software Software Training (Europe and Asia)
The VGE tool is required to generate custom Modbus mapping tables.
