NAE55/NIE55
Installation Instructions
MS-NAE55xx-x
MS-NIE55xx-x
Application
The Network Automation Engine (NAE) and Network
Integration Engine (NIE) are Web-enabled,
Ethernet-based, supervisory devices that monitor and
control networks of field-level building automation
devices, HVAC equipment, and lighting. Figure 1
shows a typical NAE55 model.
This document describes how to install MS-NAE55xx-x
and MS-NIE55xx-x model engines, which are referred
to collectively as NAE55 unless specified otherwise.
North American Emissions Compliance
United States
This equipment has been tested and found to comply with
the limits for a Class A digital device pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
this equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause
harmful interference, in which case the user will be
required to correct the interference at his/her own
expense.
Canada
This Class (A) digital apparatus meets all the
requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la Classe (A) respecte toutes
les exigences du Règlement sur le matériel brouilleur du
Canada.
Installation
Follow these guidelines when installing an NAE55:
•
Transport the NAE55 in the original container to
minimize vibration and shock damage to the
NAE55.
•
Verify that all the parts shipped with the NAE55.
The data protection battery and NAE55 ship
together but are packaged separately.
Part No. 24-10051-35, Rev. A
•
Do not drop the NAE55 or subject it to physical
shock.
•
Do not open the NAE55 housing (except the data
protection battery compartment). The NAE55 has
no user-serviceable parts inside.
Parts Included
•
one NAE55
•
one data protection battery
•
one installation instructions sheet
Materials and Special Tools Needed
•
four fasteners appropriate for the mounting surface
(M4 screws - Europe, #8 screws - North America)
•
two 36 cm (14 in.) or longer pieces of DIN rail for
DIN rail mount applications only
•
a small straight blade screwdriver for securing
communication wires in the terminal blocks
Mounting
Location Considerations
IMPORTANT: UL 864 Listed NAE55/NIE55 models
(MS-NAE5510-0U and MS-NIE5510-0U) must be
mounted in a lockable enclosure.
Follow these guidelines when mounting an NAE55:
•
Ensure that the mounting surface can support the
NAE55 and any user-supplied enclosure.
•
Mount the NAE55 in the proper orientation
(Figure 4 and Figure 5).
•
Mount the NAE55 on an even surface in wall
mount applications whenever possible. If you must
mount the NAE55 on an uneven surface, be
careful not to crack the wall mount feet or housing
when tightening the screws. Use shims or washers
to mount the unit securely on the mounting surface.
NAE55/NIE55 Installation Instructions
Release 3.1 Europe
Issued January 10, 2012
Supersedes June 4, 2008
1
Advertisement
Table of Contents
Related Manuals for Johnson Controls NAE55 Series
Summary of Contents for Johnson Controls NAE55 Series
- Page 1 NAE55/NIE55 Installation Instructions Part No. 24-10051-35, Rev. A MS-NAE55xx-x Release 3.1 Europe MS-NIE55xx-x Issued January 10, 2012 Supersedes June 4, 2008 Application • Do not drop the NAE55 or subject it to physical shock. The Network Automation Engine (NAE) and Network Integration Engine (NIE) are Web-enabled, •...
- Page 2 FC Bus (N2 Trunk, 6-Pin Modular RS-232-C FC Bus) 24 VAC ORKS Terminals Modem Serial Ports Terminal Power Terminal Jack Ports End-of-Line (EOL) Switches RJ-45 8-Pin Ethernet Jack Wall Mount Data Feet Protection Battery Compartment System Status 226 mm Light-Emitting Diodes (8.9 in.) (LEDs) System...
-
Page 3: Power Supply, Network, And Communication Connections
Mounting the NAE55/NIE55 Wall Mount Applications To mount the NAE55 on a vertical surface: 1. Mark the location of the four holes (for the wall mount feet) on the wall using the dimensions in Figure 3 and according to an orientation in Figure 4. - Page 4 Power Supply Computer Serial Ports IMPORTANT: Install the data protection battery IMPORTANT: Do not use computer serial ports in before applying 24 VAC power to the NAE55. See normal product operation for UL 864 Listed smoke the Installing the Data Protection Battery section. control applications.
- Page 5 If the American Power Conversion (APC®) • Route the supply power wires and communication ProtectNet® model PNET1 Ethernet/token ring port cables at least 50 mm (2 in.) away from the vent surge protector is necessary as described in the slots in the sides of the NAE55 housing. Metasys System Extended Architecture Smoke Control •...
-
Page 6: Wiring Considerations And Guidelines For Network Integrations
Network Terminal Block ORKS Note: Power supply wire colors may be different on and Wiring Connections transformers not manufactured by Johnson Controls. Follow the transformer manufacturer’s instructions and 4. Make connections to the RS-232 serial ports (if the project installation drawings. - Page 7 Table 2: Guidelines for BACnet Protocol MS/TP Network Topology Category Rules/Maximums Allowed General MS-NAE55xx-x models (only) support up to two MS/TP Bus trunks, daisy chain topology only. Number of Devices devices per FC Bus with no more than two repeaters between NAE55 and any device and a maximum of 50 devices between repeaters Line Length and Type 1,500 m (5,000 ft) cable without a repeater...
-
Page 8: Setup And Adjustments
Table 6: Maximum Number of Devices per L Network Segment ORKS Device Type Maximum Allowed FTT-10 Nodes Only 64 (if repeaters are not used) FTT-10 Nodes Only 128 (if repeaters are used) ([FTT10 x 2] + LPT10) < 128 Mixed FTT-10 and LPT-10 Nodes Physical Layer Repeaters Maximum of 1 per segment Terminators... -
Page 9: Troubleshooting
Setting the End-of-Line Switches When the 24 VAC supply power to the NAE55 is disconnected or lost, the NAE55 is nonoperational. The The network devices at each end of an FC Bus POWER LED (Figure 11) remains On, and the data segment must be set as network terminated devices. -
Page 10: System Re-Boot Switch
The total time to start up the NAE55 depends on the Press the System Re-Boot switch only if the NAE55 size of the database and can take several minutes. fails to respond and cannot be accessed by any user device. Do not press the System Re-Boot switch System Re-Boot Switch unless you have tried other reasonable means to fix the The System Re-Boot switch (Figure 1) forces a manual... -
Page 11: Repair Information
Repair Information Refer to the Replacing an NAE section in the NAE Commissioning Guide (LIT-1201519) for information on If you replace an NAE for any reason or add a new replacing an NAE and configuring the new NAE to NAE to a site, you must update the site registration to communicate in a Metasys system site. -
Page 12: Technical Specifications
Technical Specifications NAE55 and NIE55 (Part 1 of 2) Power Requirement Dedicated nominal 24 VAC, Class 2 power supply (North America), Safety Extra-Low Voltage (SELV) power supply (Europe), at 50/60 Hz (20 VAC minimum to 30 VAC maximum) Power Consumption 50 VA maximum Ambient Operating 0–50°C (32–122°F);... - Page 13 The performance specifications are nominal and conform to acceptable industry standard. For application at conditions beyond these specifications, consult the local Johnson Controls® office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
