Table 14: Maximum number of devices per LonWorks network segment
Device Type
Notes:
• Each LPT10/11 channel segment (between repeaters) requires its own power supply. Other factors, such
as power consumption of individual LPT10/11 devices, may limit a segment to fewer devices.
• The MS-NAE552x-x models that support LonWorks Network trunks do not have an internal network
terminator.
Table 15: NAE55 with integrations dual trunk options
Trunk Type
Modbus
M-Bus
Modbus and M-Bus
KNX
20 NAE55/NIE55 Installation Guide
Maximum Allowed
Supported Dual Trunk Application
• 2 RS485 or
• 2 RS232 or
• 2 TCP or
• 1 RS232 + 1 RS485 or
• 1 RS232 + 1 TCP or
• 1 RS485 + 1 TCP
• 2 RS485 or
• 2 RS232 or
• 2 TCP or
• 1 RS232 + 1 RS485 or
• 1 RS232 + 1 TCP or
• 1 RS485 + 1 TCP
• 1 RS485 Modbus + 1 RS485 M-Bus or
• 1 RS232 Modbus + 1 RS232 M-Bus or
• 1 TCP Modbus + 1 TCP M-Bus or
• 1 RS232 Modbus + 1 RS485 M-Bus or
• 1 RS485 Modbus + 1 RS232 M-Bus or
• 1 TCP Modbus + 1 RS232 M-Bus or
• 1 TCP Modbus + 1 RS485 M-Bus or
• 1 RS232 Modbus + 1 TCP M-Bus or
• 1 RS485 Modbus + 1 TCP M-Bus
• 1 KNX (routing mode) or
• 3 KNX (tunneling mode)
