CIS VISION:elite VCC-F60U29GE Operational Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-F60U29GE
Rev.900-682-30-00
English
2M Pixel Color
(RAW&RGB) Gig-E Camera
VCC-F60U29GE
Product Specification
& Operational Manual
CIS Corporation
©2008 CIS Corporation. All rights reserved.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISION:elite VCC-F60U29GE and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VISION:elite VCC-F60U29GE

Summary of Contents for CIS VISION:elite VCC-F60U29GE

  • Page 1 VCC-F60U29GE Rev.900-682-30-00 English 2M Pixel Color (RAW&RGB) Gig-E Camera VCC-F60U29GE Product Specification & Operational Manual CIS Corporation ©2008 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    10. Initial Settings ..........................18 11. CCD Optical Axis Accuracy ......................19 12. Dimensions ............................ 20 13. Cases for Indemnity (Limited Warranty) ................... 22 14. CCD Pixel Defect ..........................23 15. Product Support ..........................23 ©2008 CIS Corporation. All rights reserved.

  • Page 3: Scope Of Application

    Do not apply excessive voltage.(Use only the specified voltage.) Unstable or improper power supply voltage may cause damages or malfunction of the camera. The voltage ripple of camera power DC +12V±10% shall be within ±50mV. Improper power supply voltage may cause noises on the video signals. ©2008 CIS Corporation. All rights reserved.

  • Page 4: Product Outline

    Camera □ iPORT Software Development Kit 2.4.1 build 921. ※ □ Gig-E Camera Control Software (CamCtlSetup.exe) ※ □ Start up manual □ Please ask for the details or download it from our web. ※ ©2008 CIS Corporation. All rights reserved.

  • Page 5: Specification

    Approx. 190 g Lens mount C mount (Refer to overall dimension drawing) Optical axis accuracy Refer to drawing for CCD Optical Axis Accuracy (Clause 11) 0～+12dB Gain variable range 2800K～9000K White balance adjustment range ©2008 CIS Corporation. All rights reserved.
  • Page 6 RH 20～80% with no condensation Humidity LAN Card Intel PRO/1000 series LAN Cable MOD-YSP-A1AS-SP series (Honda Tsushin Kogyo) Recommended System MV series (CEI) Windows 2000 and over Memory Over 512 MB (over 1GB recommeded) ©2008 CIS Corporation. All rights reserved.

  • Page 7: Camera Output Signal Specification

    180Ω TTL Out(b) UDZS TE-17 6.2B SN74LV125A(TI) (ROHM) Vih : Vcc × 0.7(Min) Vil : Vcc × 0.3(Max) Voh : 2.48V(Min) ※(a):0～3 Vol : 0.44V(Max) (b):0～2 12 pins circular connector at rear GPIO interface ©2008 CIS Corporation. All rights reserved.

  • Page 8: Ccd Spectral Response (Representative Value)

    ・ Area of interest Width : 1624 Height : 1224 Offset X : 0 Offset Y : 19 ・ Bayer Pattern GBRG ・ (2) RGB Mode ・RGB Color, 24bit, Packed ・ Area of interest Width : 1624 Height : 1224 Offset X : 0 Offset Y : 19 ©2008 CIS Corporation. All rights reserved.

  • Page 9: Function Settings

    Address 009 MSB and address 010 LSB makes total 16 bit. RAW Mode: Shutter speed = (1251-(009&010)) x 30.00μs + 20.84μs RGB Mode: Shutter speed = (1251-(009&010)) x 60.00μs + 41.69μs Max data = 1251 Positive Input Trigger Polarity Negative Input ©2008 CIS Corporation. All rights reserved.
  • Page 10 Input 083 or 053 to save the data in EEP-ROM. Note: When setting the data with 2 Byte, High Byte shall be set first, then Low Byte to the next. The camera rewrites the internal resister when receiving Low Byte. ©2008 CIS Corporation. All rights reserved.

  • Page 11: External Connector Pin Assignment

    ※ Pin assignment and functions can be set arbitrarily via iPORT software. ※ Pin assignment and functions can be set arbitrarily via iPORT software. Please refer to iPORT.Software.Coyote.pdf Please refer to iPORT.Software.Coyote.pdf in￥Program Files￥Pleora Technologies Inc￥iPORT in￥Program Files￥Pleora Technologies Inc￥iPORT Software￥Documentation. Software￥Documentation. ©2008 CIS Corporation. All rights reserved.

  • Page 12: Gigabit Ethernet Connector Mod-Ysj88Da03C-Cn+ (Honda Tsushin Kogyo Co., Ltd)

    6.2. RJ-45 Gigabit Ethernet Connector MOD-YSJ88DA03C-CN+ (HONDA TSUSHIN KOGYO CO., LTD) LINK(Green LED) ACT( Yellow LED ) LINK LED: Lighting-off ・・・Unconnected to LAN Lighting-on ・・・Connected to LAN Blinking ・・・Transmitting the data ACT LED: Lighting-off ・・・Unconnected or connected with 10Mbps/100Mbps Lighting-on ・・・Connected with 1000Mbps ©2008 CIS Corporation. All rights reserved.

  • Page 13: Timing Chart

    RAW Mode = 64MHz RGB Mode = 32MHz 7.2. Full Frame Scan Mode Timing Video Output 1224H 1224H (CCD Read Out Signal) 1248 1249 1250 1251 1252 LVAL Output DVAL Output FVAL Output Total = 1252H ©2008 CIS Corporation. All rights reserved.

  • Page 14: Standard Trigger Mode Timing

    FVAL Output 1243H RAW Mode(CLK 64MHz) TTL INx 1.08μs (Trigger Input) nHD×30μs + 20.84μs (Sub Pulse) RGB Mode(CLK 32MHz) 2.16μs (CCD Read Out Signal) nHD×60μs + 41.69μs SP Output Delay(Fixed) (Exposure Signal) Exposure Time ©2008 CIS Corporation. All rights reserved.

  • Page 15: Pulse Width Trigger Timing

    1252 DVAL Output FVAL Output 1243H RAW Mode(CLK 64MHz) TTL INx 1.08μs (Trigger Input) 21.92μs (Sub Pulse) RGB Mode(CLK 32MHz) 2.16μs (CCD Read Out Signal) 43.84μs SP Output Delay(Fixed) Delay(Fixed) (Exposure Signal) Exposure Time ©2008 CIS Corporation. All rights reserved.

  • Page 16: Partial Scan Mode Details

    ・ 768 H 948 H 35 fps 18 fps ・ ・ ・ ・ ・ 1026 H 1120 H 30 fps 15 fps ・ ・ ・ ・ ・ 1224 1252 H 27 fps 13 fps ©2008 CIS Corporation. All rights reserved.

  • Page 17: Remote Interface Function

    To save the data into EEPROM, please refer to Section 5. Function Settings. C is the code to send the data back from the camera. Note: Do not set code C when sending the data from PC side. ©2008 CIS Corporation. All rights reserved.

  • Page 18: Initial Settings

    0: Positive Input Output Data Select 0: 8 bit Output Data Partial Scan Mode 0: Full Frame Scan Mode Camera Mode 1: RGB (24bit) Mode Partial Scan Total Lines 021 & 022 1251: Read Only ©2008 CIS Corporation. All rights reserved.

  • Page 19: Ccd Optical Axis Accuracy

    φ0.6 to the center of the lens mount. Inclination of effective pixels θ Datum Plane A To datum plane A shall be θ≦±0.5° *)Dimension from datum plane A to the center of lens mount. 910-003-00-00 (Unit :mm) ©2008 CIS Corporation. All rights reserved.

  • Page 20: Dimensions

    Product Name Label Position *1) C Mount screws comply with ANSI/ASME B1.1, 1-32UN(2B). *2) Screw length from C mount lens surface shall be under 6mm. And protruding portion shall be 999-500-00-00(1/2) lesss than 10mm. (Unit:mm) ©2008 CIS Corporation. All rights reserved.
  • Page 21 VCC-F60U29GE Rev.900-682-30-00 (51) (19) CCXC-12PxxN (31) (23) (SONY) 2 MEGA PIXEL MOD-YSP-A1AS-SP()+ (HONDA TSUSHIN KOGYO) Cable Reference Drawing 999-500-00-00(2/2) (Unit:mm) ©2008 CIS Corporation. All rights reserved.

  • Page 22: Cases For Indemnity (Limited Warranty)

    In case damage or losses are caused by repair or modification conducted by the customer or any unauthorized third party (such as an unauthorized service representative). Expenses we bear on this product shall be limited to the individual price of the product. ©2008 CIS Corporation. All rights reserved.

  • Page 23: Ccd Pixel Defect

    On very rare occasions, however, CCD pixel defects might be noted with time of usage of the products. Cause of the CCD pixel defects is the characteristic phenomenon of CCD itself and CIS is exempted from taking any responsibilities for them.
