Haversham - 3 Dr 3 Drw Sideboard
Assembly Instructions
Dimensions
Width - 120cm
Depth - 39cm
Height - 80,5cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800
- Please keep for future reference
159/9280
Issue 1 - 01/10/10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Haversham
Summary of Contents for Argos Haversham
- Page 1 Haversham - 3 Dr 3 Drw Sideboard Assembly Instructions - Please keep for future reference 159/9280 Dimensions Width - 120cm Depth - 39cm Height - 80,5cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly . Check you have all the . We do not This product contain components and tools listed on Natural timber; you may recommend the pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 3 Components - Panels Please check you have all the panels listed below Left front leg ( Right front leg ( 78,5 x 4,5cm 78,5 x 4,5cm Left back leg ( Right back leg ( 78,5 x 4,5cm 78,5 x 4,5cm Door X 3 9 x 36,2cm Top panel...
-
Page 4: Tools Required
Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 Assembly Instructions Assembly Instructions Step 1 Parts are labelled for easier identification. Insert wooden dowels into large runners Insert wooden dowels into leg as shown. Screw metal dowels into leg Do note over tighten metal dowels. Step 2 a) Fit side panel , left front leg and left back...
-
Page 6: Front View
Assembly Instructions Step 3 a) Fit side panel , right front leg and right back together. b) Insert locking nuts where shown. Use a screwdriver to turn locking nuts clockwise to lock. Fix hinge plates using screws as shown. Fix runner to side panel using screws . - Page 7 Assembly Instructions Step 5 Fix large middle wall to base panel using screws Step 6 Fix shelf using screws Step 7 Fix assembled right side panel using screws as shown.
- Page 8 Assembly Instructions Step 8 Fix assembled left side panel using screws as shown. Step 9 Fix small middle wall the top panel using PAINTED EDGE screws . Screw metal dowels where shown. ATTENTION! Make sure panels are positioned as show in the picture.
- Page 9 Assembly Instructions Step 10 Fix top panel to the assembled part using screws . Insert locking nuts as shown. Use a screwdriver to turn locking nuts clockwise to lock. Fix central foot using screw Step 11 With the help of a hammer, fix foot pads as shown.
- Page 10 Assembly Instructions Step 12 Make sure holes face this side Fix runners using screws . Make sure holes in runners are positioned as shown. Step 13 Position back panels within rebates with profile in place as shown. Attach back panels using nails and where shown, use squared...
- Page 11 Assembly Instructions Step 14 Insert wooden dowels into drawer sides Attach drawer sides to drawer front using screws Step 15 Slide drawer base into grooves as shown. Attach drawer back using screws Fix handle using screw Step 16 Attach hinges N to the doors 4 using screws J as shown.
- Page 12 Assembly Instructions Step 17 Fixing wall strap: Fix wall strap H to top of product (edge) using washer I and screw J as shown. Insert wooden dowels into the runners as shown. Hanging doors: With help, slot door hinges N onto hinge plates M and tighten screws.
-
Page 13: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. Make sure that the screws and wall plugs being used If plastic wall plugs are supplied with your are suitable for supporting your unit.
