Summary of Contents for Argos Austen HOME 804/3416
- Page 1 Austen Spare Parts Customer Support 0345 640 2020 www.argos-support.co.uk Help@ClickSpares.co.uk 0370 112 1928 Issue 1 - 10/06/19...
- Page 2 When lifting the bed remove all bedding - Except the fitted sheet. Sainsbury's Argos is a trading name of both: Argos Limited, Registered office: 489-499 Avebury Boulevard, Milton Keynes, United Kingdom, MK9 2NW, registered number: 01081551 (England and Wales); and Sainsbury's Supermarkets Limited, Registered...
- Page 3 Fittings (Shown to scale) 8x45mm Bolt x 8 8x25mm Bolt x 28 8x30mm Bolt x 10 4x45mm Wood screw x 16 17mm Flat washer x 46 Nut x 6 12mm Spring washer x 20 5mm Allen key x 1 Spanner x 1 5x50mm Wood screw x 8 Box spanner x 1...
- Page 4 Parts INSIDE Right side rail (4'6-1930 × 310mm)(5'-2030 × 310mm) FRONT INSIDE Left side rail (4'6-1930 × 310mm)(5'-2030 × 310mm) Headboard (4'6-1490 × 1000mm) (5'-1640 × 1000mm) INSIDE Footboard (4'6-1450 × 310mm) Hinge Mechanism (x 1 pair) NOTE: PISTON ATTACHED (5'-1600 ×...
- Page 5 Parts Double slat caps x 14 (4'6-55mm) Stretcher x 1 (4'6-1390 × 25mm) Double slat caps x 15 (5'-55mm) (5'-1540 × 25mm) Corner bracket x 4 (120 × 80mm) Mattress support bracket x 2 Single slat caps x 28 (4'6-55mm) Feet x 2 (100 x 40mm) Single slat caps x 30 (5'-55mm) Feet x 2 (100 x 40mm)
-
Page 6: Tools Required
Tools required Ruler/tape Allen key (Supplied) measure Spanner (Supplied) Phillips screwdriver (small & medium) Box spanner (Supplied) - Page 7 8x45mm Bolt x 8 8x25mm Bolt x 28 8x25mm Bolt x 8 17mm Flat washer x 8 12mm Spring washer x 8 8x30mm Bolt x 10 4x45mm Wood screw x 16 17mm Flat washer x 46 Nut x 6 12mm Spring washer x 20 5mm Allen key x 1 5x50mm Wood screw x 8 Spanner x 1...
- Page 8 5mm Allen key x 1 4x45mm Wood screw x 16 Ensure frame is square...
- Page 9 Turn Product 5x50mm Wood screw x 8...
- Page 10 Turn Product 8x30mm Bolt x 10 17mm Flat washer x 10 5mm Allen key x 1 8x25mm Bolt x 4 17mm Flat washer x 4 5mm Allen key x 1...
- Page 11 8x25mm Bolt x 12 17mm Flat washer x 12 12mm Spring washer x 12 5mm Allen key x 1 Turn Product 8x25mm Bolt x 4 17mm Flat washer x 4 5mm Allen key x 1...
- Page 12 Nut x 6 8x45mm Bolt x 6 17mm Flat washer x 6 5mm Allen key x 1 Spanner x 1 Box spanner x 1...
- Page 13 Repeat Repeat...
- Page 14 (for full list of exclusions please visit https://argos.productaftercare.co.uk or visit an Argos store for more information).
