INDUSTRIAL STYLE DESK WITH DRAWER
797/1699
- Please keep for future reference

Dimensions

Width - 120cm
Depth - 60cm
Height - 75cm

Important

– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Argos Aftersales
Helpline: 0345 640 0800
Issue3 - 20/09/2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HOME 797/1699 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Argos HOME 797/1699

  • Page 1 Width - 120cm Depth - 60cm Height - 75cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Argos Aftersales Helpline: 0345 640 0800 Issue3 - 20/09/2017...
  • Page 2 To reduce the likelihood of damaging your product, please ensure that your power drill is set on a low torque setting. Note: if required the next page can be cut out and used as reference throughout the assembly. Keep this page with these instructions for future reference.
  • Page 3 Table Top x 1 Left Leg x 1 Right Leg x 1 (120 x 60cm) (73.5 x 59cm) (73.5 x 59cm) Back Board x 1 Side Board x 1 Side Board x 1 (37 x 12cm) (50.5 x 12cm) (50.5 x 12cm) Supporting Bar x 2 Supporting Bar x 1 Drawer Front x 1...
  • Page 4 Camlock Screw(22mm) x 18 Dowel (Ø8 x 30mm) x 8 Camlock Nut(Ø15mm) x 18 Bolt( M6 x 25mm) x 2 Runner(390mm) x 2 Screw (Ø3.5 x 14mm) x 12 Bolt (M6 x 12mm) x 13 Bolt( M6 x 30mm) x 6 Allen Key(62 x 6mm) x 1...
  • Page 5 Assembly Instructions Assembly Instructions Step 1 a: Insert camlock nut C x 6 into back board 4 . b: Insert camlock nut C x 2 into side board 6 . Insert camlock screw A into side board 6 . Attach runner D to side board 6 by using screw E x 3 .
  • Page 6 Assembly Instructions Step 5 Attach supporting bar 8 to the assembled part by using bolt F x 2. Step 6 Attach cross bar 14 to left leg 2 and right leg 3 by using bolt G x 4 for each. Step 7 Attach the assembled leg to the table top 1 by using bolt...
  • Page 7 Assembly Instructions Step 9 a: Insert camlock nut C x 2 and camlock screw A into drawer side 10 b: Repeat a for drawer side 11 c: Insert camlock nut C x 4 into drawer back 12 Step 10 a: Attach drawer side 10 & 11 to drawer back 12 b: Use a screw driver to turn camlock nut clockwise to...
  • Page 8 Assembly Instructions Step 13 a: Attach runner to drawer Side 10 by using screw E x 3 b: Repeat a for drawer side 11 Step 14 a: Insert the drawer Assemble is complete.
