LARGE TRESTLE TABLE DESK

Assembly Instructions

616/9639

- Please keep for future reference

Dimensions

Width - 140cm

Depth - 60cm

Height - 75cm

Important

– Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Argos Aftersales

Helpline: 0345 640 0800

Issue 3 - 20/07 / 201 6

Need help?

Do you have a question about the HOME LARGE TRESTLE TABLE DESK and is the answer not in the manual?

Page 1 Depth - 60cm Height - 75cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Argos Aftersales Helpline: 0345 640 0800 Issue 3 - 20/07 / 201 6...
Page 2 To reduce the likelihood of damaging your product, please ensure that your power drill is set on a low torque setting. Note: if required the next page can be cut out and used as reference throughout the assembly. Keep this page with these instructions for future reference.
Page 3 Table top Bottom board x 2 Frame x 4 ( 140 X 60 CM ) ( 54.5 X 29.5 CM ) ( 33 X 73.5 CM ) Cross bar x 2 Cross bar x 4 Cross bar ( 55 X 2 CM ) ( 55 X 1.8 CM ) ( 102 X 2 CM ) Supporting bar x 4 (74 X Ø0.6 CM )
Page 4 Bolt (Ø6mm x 12 mm ) x 10 Bolt (Ø6mm x 28 mm ) x 8 Bolt (Ø6mm x 32 mm ) x 21 Spanner x 1 Bolt (Ø6mm x 60 mm ) x 2 Nut x 2 Allen key (68 x 25mm) x 1...
Page 5 Assembly Instructions Assembly Instructions Step 1 Attach cross bar 4 & 5 to frame 3 by using screw for each. Please do not tighten all the screws until step b is completed. Attach the shelf 2 to the assembled section by using 4 x screw Repeat the above for the other one.
Page 6 Assembly Instructions Assembly Instructions Step 2 Attach crossbar 6 to the assembled section by using 2 x screw Step 3 Attached table top 1 to the assembled section by using 5 x screw Assembly is complete.
