Mid back office chair

Advertisement

Quick Links

Mid back Office Chair
Assembly Instructions -
Dimensions
Width - 53cm
Depth - 54cm
Height - 89-101cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800
Please keep for future reference
617/9296
Issue 1 - 11/10/16

Advertisement

loading
Need help?

Need help?

Do you have a question about the HOME 617/9296 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Argos HOME 617/9296

  • Page 1 Width - 53cm Depth - 54cm Height - 89-101cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 640 0800 Issue 1 - 11/10/16...
  • Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • We do not components and tools listed on or put weight on the product, this recommend the the following pages.
  • Page 3: Components - Parts

    Components - Parts If you have damaged or missing components, call the Customer Helpline: Argos = 0345 640 0800 Please check you have all the parts listed below 1 Backrest 2 Back Frame 3 Chair Lift Plate (43 x 42 x 9cm)
  • Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. M6 x 35mm Bolt x 6 M6 x 18mm Bolt x 4 M6 x 25mm Bolt x 2 Allen Key x 1...
  • Page 5 Assembly Instructions Step 1 Attaching armrests Attach the armrest to the seat . Then align the holes and fix using bolts and small arrow washer . Tighten bolts using allen key Step 2 FRONT Attaching the chair lift plate Place the seat upside down on a raised protected surface.
  • Page 6 Assembly Instructions Step 3 Step 3 Attaching back rest metal rod Insert the metal part of the back connector into metal rod on the back frame shown. Then attach the back frame to backrest as shown and fix using the plastic part of the back connector bolts .
  • Page 7 Assembly Instructions Step 5 Attaching back rest Then attach the back frame into the chair lift plate by inserting into the slot hole as shown. Secure using the knob and washer and tighten by turning it clockwise. Note: The two bolts at this stage is fully tightened Step 6 Attaching castors...
  • Page 8 Assembly Instructions Step 7 Step 3 Attaching gas lift Insert the gas lift into hole on the base shown & secure by pressing down firmly. Then insert the plastic sleeve on the gas lift Step 8 Attaching seat Position the seat as shown and insert the gas lift into the hole on...
  • Page 9 To lower the seat, pull up the lever while seated on the chair. Pull up lever to adjust seat height Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 640 0800...
