Summary of Contents for Argos Home Venetia
- Page 1 Venetia 886/8471 886/0967 A I N N - W Spare Parts Customer Support Visit: www.argos-support.co.uk Call: 0345 640 2020 Email: Help@ClickSpares.co.uk Call: 0330 016 1114 Issue 4 - 30/12/19...
-
Page 2: Care Advice
Safety Important - Please read these instructions fully before starting assembly • WARNING: To prevent • Warning: This unit weighs possible overbalancing this unit approximately 45kgs. must be secured to a wall using Please lift with care. the 2 overbalance protector kits •... -
Page 3: Cabinet Panels
Cabinet Panels 3 119.2 x 32.9cm 1 83 x 31.2cm 2 83 x 31.2cm 4 119.2 x 32.9cm 6 115.7 x 7.6cm 7 12.6 x 31cm 8 76 x 30.9cm 9 37.8 x 30.9cm 5 68.9 x 31cm WOODGRAIN DOORS NON-WOODGRAIN DOORS 10 68.3 x 39.2cm 11 68.3 x 39.2cm... - Page 4 Cabinet Panels 12 78 x 85.6cm 13 40 x 85.6cm Drawer Panels WOODGRAIN DRAWER FONTS NON-WOODGRAIN DRAWER FONTS 14 58.9 x 13.8cm 14 58.9 x 13.8cm 15 58.9 x 13.8cm 15 58.9 x 13.8cm 16 30 x 9.5cm 17 30 x 9.5cm 18 54.95 x 29.1cm 19 53.85 x 9.5cm...
- Page 5 Fittings Use these drawings to correctly identify the fittings Bag 1 x 10 x 10 x 10 x 10 x 12 x 35 x 20 Bag 2 x 10...
- Page 6 Fittings WOODGRAIN UNIT HANDLES NON-WOODGRAIN UNIT HANDLES Tools Only used for drilling walls...
- Page 7 Fitting Ball Bearing Runners www.youtube.com/watch?v=yG4x�JJeSg Bag 1 x 10 x 10 x 10 x 10 x 12 x 35 x 20 2nd hole 2nd hole...
- Page 9 Hinge Fixing and Door Adjustment www.youtube.com/watch?v=wIMhUHeLBtg...
- Page 10 Finished front edge Finished front edge Finished front edge...
- Page 11 Finished front edge...
- Page 12 Finished front edge Only use 1 Screw to fit each Bracket Finished front edge...
- Page 13 Fitting Ball Bearing Runners www.youtube.com/watch?v=yG4x�JJeSg 2nd hole NOTE: Due to the manafaturing Finished process, the 2 large 15mm holes front edge can be on either surface Turn the panel over Finished front edge 2nd hole...
- Page 14 Finished front edge Finished front edge IMPORTANT: The Plastic Nails must be in line with the bottom edge of the Sides and Divider...
- Page 15 Finished front edge...
- Page 16 Squaring up a Chest and fitting the Back Panel www.youtube.com/watch?v=FeaI6541z7o A = B Make sure measurement A and B are the same before attaching parts 12 and 13 IMPORTANT: Do not nail where the 2 backs meet and put 4 roofing nails aside to fit the back holders. x 31...
- Page 18 WARNING! In order to prevent overturning this product must be used with the 2 wall attachment devices provided See the next section for a guide to wall mounting and fixings Slide the Brackets against the wall. Fit the 2nd screws supplied with the Brackets into the underside of the Top panel.
-
Page 19: A Guide To Wall Mounting & Fixings
A Guide to Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit. - Page 20 For each shelf, insert 4 shelf studs at the required height. x 20...
- Page 21 x 12 Hinge Fixing and Door Adjustment www.youtube.com/watch?v=wIMhUHeLBtg WOODGRAIN DOORS NON-WOODGRAIN DOORS...
- Page 22 Hinge Fixing and Door Adjustment www.youtube.com/watch?v=wIMhUHeLBtg Fit the top Hinge Arm 1st, then align and fit the other Hinge Arm. a: The recess at the bottom of screw B on the Hinge Arm goes into the slot in the Hinge Plate. b: Keep the Hinge Arm flat and slide it across the Hinge Plate as far as it will go, then tighten screw A.
- Page 23 WOODGRAIN UNIT HANDLES NON-WOODGRAIN UNIT HANDLES Note: Do not overtighten the screws...
- Page 24 Hinge Fixing and Door Adjustment www.youtube.com/watch?v=wIMhUHeLBtg Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the...
-
Page 25: Drawer Assembly
Drawer Assembly Bag 2 x 10 Drawer Assembly www.youtube.com/watch?v=InNBV_uuMmo NOTE: The Right Hand Drawer Front has a small identification hole x 10... - Page 27 Ensure the drawer base sits flush by turning the shelf studs clockwise or anti-clockwise...
- Page 28 WOODGRAIN UNIT HANDLES NON-WOODGRAIN UNIT HANDLES Note: Do not overtighten the screws...
- Page 29 Fitting Ball Bearing Runners www.youtube.com/watch?v=yG4x�JJeSg NOTE: The Right Hand Drawer Front has a small identification hole Warning: Use a screwdriver to position the runners as they could have sharp edges For each drawer, slide both the runners forward and locate the drawer sides between them, lining up the holes in the drawer sides with the 2nd 'threaded' holes in the runners.
- Page 30 A I N N - W Assembly is complete Please remove any blue protective film from panel edges and clear protective film from panel surfaces...
- Page 32 ALR3489...
