- Page 1 Apartment Tall Boy Spare Parts Customer Support 0345 640 2020 www.argos-support.co.uk Help@ClickSpares.co.uk 0370 112 1928 Issue 2 - 09/11/19...
-
Page 2: Product Details
Safety and Care Advice Product Details 272/1813 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. Keep children and animals Assemble the item as close We do not away from the work area, small recommend the room) as possible. parts could choke if swallowed. use of power drill/drivers for Make sure you have enough space... - Page 3 Fittings Metal Dowel x 20 Locking Nut x 20 8x30mm Wooden Dowel x 20 Handle x 1 30 mm Screw x 1 14mm Screw x12 Cam Cap x 8 14mm Screw x 2 Hanger Bracket x 2 45 mm Screw x 6 Metal Support x 12 Hardware Hinge ×2...
-
Page 4: Tools Required
Tools required Phillips screwdriver Ruler/tape (small & medium) measure Phillips screwdriver Eye protection (small & medium) (when using a hammer or glue) Large hammer Power Drill Pencil Drill Heads Ladder... - Page 5 Panels Top panel (350 x 300mm) Upper adjustable shelf x 2 (318 x 284mm) Right side panel Upper shelf Left side panel (1540 x 299mm) (1540 x 299mm) (318 x 284mm) Lower adjustable shelf Lower shelf (318 x 265mm) (318 x299mm) Lower back panel Upper back panel Door panel...
- Page 6 Metal Dowel x 20 Locking Nut x 20 8x30mm Wooden Dowel x 20 Handle x 1 30 mm Screw x 1 14mm Screw x12 Locking Nut x4 Cam Cap x 8 14mm Screw x 2 Hanger Bracket x 2 45 mm Screw x 6 Metal Support x 12 Metal Dowel x 4 Repeat...
- Page 7 Metal Dowel x 4 Turn Product Metal Dowel x 8...
- Page 8 Locking Nut x4 8 x30mm Wooden Dowel x 4 Locking Nut x4 8x30mm Wooden Dowel x 4...
- Page 9 Locking Nut x4 8 x30mm Wooden Dowel x 4 Turn Product Hanger Bracket x 2 Metal Dowel x 4 14mm Screw x 2...
- Page 10 Locking Nut x4 Metal Support x 12 8 x30mm Wooden Dowel x 4 Turn Product...
- Page 11 30 mm Screw x 1 14mm Screw x4 Handle x 1 Hinge Left Hand Opening 14mm Screw x8...
- Page 12 Cam Cap x 8 Right Hand Opening...
- Page 13 Wall fixings are not supplied. Please refer to A Guide To Wall Mounting & Fixings, page 14. WARNING!
-
Page 14: A Guide To Wall Mounting & Fixings
A Guide to Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
