Johnson Controls tyco RAPID RESPONSE RCP-1 Manual page 6

TFP485
Page 6 of 14
8"
(200 mm)
1-3/4"
(45 mm)
(127 mm)
(1270 mm)
LEFT SIDE
Nominal Weight:
95 LBS. (43 kg)
14"
(355 mm)
2-7/8"
(73 mm)
5" OPERATOR
INTERFACE
WINDOW
50"
FRONT
MODEL RCP-1 RESIDENTIAL CONTROL PANEL ASSEMBLY
BACKUP
BATTERIES
AIR
PRESSURE
CONTROL
DISCONNECT
"ON/OFF"
SWITCH
OUTLET
CONNECTION
TO DRY PIPE FIRE
PROTECTION
SYSTEM
SYSTEM
AIR SUPPLY
PRESSURE
GAUGE
SYSTEM
WATER SUPPLY
PRESSURE
GAUGE
MANIFOLD
ASSEMBLY
HINGED
LOCKING
PANEL DOOR
AIR
PRESSURE
CONTROL
MOUNTING
BRACKETS
ENCLOSURE
(PANEL DOOR
NOT SHOWN)
FIGURE 3
ELECTRONIC
CONTROL
SYSTEM
*
WATER SUPPLY
CONNECTION CONNECTION
*
Always consult local jurisdictions for water
supply criteria and requirements.
OPERATOR
INTERFACE
SYSTEM
DRAIN
