SMC Networks MHM-16D Series Operation Manual page 7

1) Lateral mounting
Model
Applicable bolt
MHM-16D□
MHM-25D□
MHM-32D□
MHM-50D□
2) Axial mounting (Central mounting type)
Model Applicable bolt
MHM-16D□
MHM-25D□
MHM-32D□
MHM-50D□ M12x1.75
3) Axial mounting (Body tapped)
Model Applicable bolt
MHM-16D□
MHM-25D□
MHM-32D□
MHM-50D□
4. The pressing load applied to the workpiece should be smaller than the
allowable pressing load.
Allowable
Model pressing load
MHM-16D□
MHM-25D□
MHM-32D□
MHM-50D□
5. Do not apply impact load to the center of the magnetic attraction surface.
Otherwise, it may result in a breakage or malfunction.
6. The head cap is magnetized during the release of workpiece.
Iron particles may be attracted.
Tightening
torque
(N･m)
M3x0.5 0.63
M4x0.7 1.5
M5x0.8
M6x1 5.2
Tightening
torque
(N･m)
M6x1 5.2
M8x1.25 12.5
M10x1.5 24.5
42
Tightening
torque
(N･m)
M3x0.5 0.63
M4x0.7 1.5
M5x0.8
M6x1 5.2
(N)
100
200
300
500
Max. screw-in
depth L(mm)
5
7
3 8
9
Max. screw-in
depth L(mm)
11.5
12.4
13.5
16
Max. screw-in
depth L(mm)
6
8
3 10
12
- 7 -
