- Retains Factory Auxiliary Input. - EIA color coded wiring for easy installation. 1. Does not support amplified systems. 2. Does not retain Rear Seat Entertainment system (RSE). 3. Does not retain factory navigation system. SWRHN-62L MODULE SWRHN-62L HARNESS 1 / 2 Rev.090117...
Page 2
SETTING THE HONDA SWC SETTING THE AFTERMARKET RADIO BRAND With the key in the off position, set the DIP switches to the corresponding radio listed below. 3.5MM SWC CABLE Use the proper 3.5MM to 4-Pin SWC cable for the aftermarket radio you are using. OPTION A is used for ALPINE, CLARION, (JVC and KENWOOD units will use the Blue/Yellow wire).
