PICMG 1.3 Backplane with One PCIe x16 Slot,
Four PCI-X Slots and Four PCI Slots
PXE-12S
Quick Installation Guide
Version 1.1
November 19, 2015

Package List

PXE-12S package includes the following items:
1 x PXE-12S PICMG 1.3 backplane
1 x QIG
Copyright © 2015 IEI Integration Corp.
All rights reserved.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PXE-12S and is the answer not in the manual?

Questions and answers

Summary of Contents for IEI Technology PXE-12S

  • Page 1 Four PCI-X Slots and Four PCI Slots PXE-12S Quick Installation Guide Version 1.1 November 19, 2015 Package List PXE-12S package includes the following items: 1 x PXE-12S PICMG 1.3 backplane 1 x QIG Copyright © 2015 IEI Integration Corp. All rights reserved.
  • Page 2 1 x Power good (1x2 pin) 1 x SMBus (1x2 pin) Dimensions: 311 mm x 328 mm Ordering Information PXE-12S-R11: PICMG 1.3 backplane with one PCIe x16 slot, four PCI-X slots and four PCI slots RACK-3000G: 4U 14-slot full-size rack-mount chassis...
  • Page 3 Jumper Settings and Connectors LABEL FUNCTION JP2, JP3 PCI-X slot frequency setting VIO_J1 PCI-X slot VIO power setting External USB 2.0 connectors from the USB1, USB2 mainboard FAN1, FAN2, FAN3, FAN4 Fan connectors Backplane to mainboard ATX power control ATXCTL1 connector PWR1 ATX power connector...
  • Page 4 VIO_J1: PCI-X slot VIO power setting OPTIONS DESCRIPTION Short 1-4, 2-5, 3-6 +3.3V Short 7-4, 8-5, 9-6 (Default) ● ● ● ● ● ● ● ● ■ USB1, USB2: External USB 2.0 connectors from the mainboard PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_VCC DATA-...
  • Page 5 PWR1: ATX powerconnector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +3.3V +3.3V -12V PSON# PWRGD +5VSB +12V +12V +3.3V 12V1: ATX 12V power source connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V +12V +12V +12V PWRBTN: External power button connector PIN NO.
  • Page 6 SM-BUS: External system management connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SMDAT SMCLK CN1: PCIe x16 SDVO control signal connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION EXP_EN SDVO_CLK SDVO_DAT IOPWR: I/O power connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION -12V +12V IPMB_DA 5VSB...
  • Page 7 PWR3, PWR4: AT +3.3V power connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +3.3V +3.3V PICMG 1.3 local PCI routing table SIGNAL REQ# GNT# IDSEL INTA# INTB# INTC# INTD# PIN NO. PCI1 REQ0# GNT0# AD31 PCI2 REQ1# GNT1# AD30 PCI3 REQ2# GNT2# AD29 PCI4...
  • Page 8 Board Layout: Jumper and Connector Locations (Unit: mm)...
