Operating Annunciators; Scs-8 Smoke Controller; Acm-16At; Acm-32R - Notifier Inertia 1010 Operator's Manual

1010/2020 O M
PERATORS ANUAL
O A
PERATING
SCS-8 S C
MOKE ONTROLLER
Each Notifier SCS-8 Smoke Control Annunciator can control up to 8 individual fans as per the requirements of
AS1668. Each fan has a 3 position switch and 3 LED indications.
The 3 positions on the switch are:
ON = Force fan to RUN, overriding all other signals.
AUTO: = Fan controlled by others but in fire mode follows programmed logic sequence.
OFF: = Force fan to STOP, overriding all other signals.
The 3 indicators are
RUN = Airflow is detected upstream from the fan.
STOP = Airflow is NOT detected upstream from the fan.
FAULT = The fan is not responding to signals given.
•
If the Stop LED is flashing, this means the fan has been shut down due to smoke being detected in the
supply air duct to the fan (Auto mode only).
•
Each fan can be individually controlled in fire-mode or in normal mode. The operation of the fan in auto
mode is programmed specific for each project.
•
The A/C trip reset button on the top of the module doubles as the lamp test button when not in fire-mode.

ACM-16AT

The Notifier ACM-16AT 16 way pushbutton Annunciator is used for single press operation of system functions.
Dependent on the configuration. Each push button also has one RED and one Amber LED. Each button can be
programmed for a different function ie:
Function of Button
Output activate/deactivate
Zone isolate/de-isolate
Module isolate/de-isolate

ACM-32R

The Notifier ACM-32R Annunciator has 32 x LED indications which are fully programmable. Each LED can
represent 1 x detector, module or zone and will illuminate red when in fire mode or when operated.

LCD-80

The Notifier LCD-80 Mimic is a remote LCD mimic which has a 4 x 20 LCD displaying text messages as per the
main system LCD. From this point you can acknowledge, scroll and reset the panel as per the main panel
control.
NNUNCIATORS
RED LED
Output Activated
Zone in alarm
Module In Alarm
C © 2000, N
OPYRIGHT
:
I P L
OTIFIER NERTIA TY
AMBER LED
Output In Fault
Zone is isolated or in Fault
Module Isolated or in Fault
TD
P 9
AGE
