Connection diagram

MPD 19N
20 19 18 17 16
R Y
S1 S2 S1 S2 S1
Range
Current: 0.5 To 5A AC, CAT III
Voltage(P-P) : 50-500V AC, CAT III
(P-N) : 30-300V AC, CAT III
CT Selection up to 2000/5Amp AC CAT III
230V AC
50Hz, 4VA !
NO C NC
L N
1 2 3 4 5
Page -5
15 14 13 12
B
S2
System:
3 Ph-4W/3 Ph-3W
Accuracy Class: 1.0
V V V
Y B
R
6 7 8 9
11
N
10
