5.

EXTERNAL DIMENSIONS

· Panel mount type
135.5 (5.33)
151.5 (5.96)
144 (5.67)
Attach the mounting bracket either on the top/bottom or on the sides.
245.1 (9.65)
29.5
2 – 26 (.08 – 1.02)
(1.16)
(panel thickness)
– 9 –
Unit: mm (inch)
