I N S T A L L A T I O N M A N U A L
X-STREAM 2™ SLIDE HARDWARE KITS
XS-101-SS – PVC LEG TO FOOT RECEIVER
QTY P RT NUMBER
8 H-SS 3/8-16X2
8 H-SS 3/8 NYLON
16 H-SS 3/8 FLT WASHER
8 H-.562 X .390 CAP
XS2-102-SS – FLUME H RDW RE
QTY P RT NUMBER
5 H-SS 3/8X2-1/2
15 H-SS 3/8 F NUT
15 H-SS 3/8 LOC WASHER
25 H-SS 3/8 FLT WASHER
10 H-SS 3/8 X 3 TAP
25 H-.562 X .390 CAP
XS-103-SS – PVC LEG TO FLUME
QTY P RT NUMBER
6 H-SS 3/8 LOC WASHER
12 H-SS 3/8 FLT WASHER
12 H-.562 X .390 CAP
6 H-SS 3/8 X 7-1/2
XS-104-SS – FOOT RECEIVER TO DECK
QTY P RT NUMBER
13 H-SS 3/8 LOC WASHER
8 H-SS 3/8 WEDGE
13 H-.562 X .390 CAP
5 H-SS 3/8 X 3-1/2 W
XS2-105-SS – H NDR IL H RDW RE
QTY P RT NUMBER
10 H-SS 5/16 X 2
4 H-SS 5/16 X 2-1/2
4 H-SS 5/16 FLA WASHER
14 H-SS 5/16 SER
4 H-.463 X .310 CAP
XS2-IM Rev. 10/14 (SBK-XS2 INSTALL)
COMPONENT DESCRIPTION
3/8" x 2" hex head bolt s.s.
3/8" nylon insert nut s.s.
3/8" x 1" flat washer s.s.
gray protective cap
COMPONENT DESCRIPTION
3/8" x 2-1/2" all-thread stud s.s.
3/8" finish nut s.s.
3/8" lock washer s.s.
3/8" x 1" flat washer s.s.
3/8" x 3" hex head tap bolt s.s.
gray protective cap
COMPONENT DESCRIPTION
3/8" lock washer s.s.
3/8" x 1" flat washer s.s.
gray protective cap
3/8" x 7-1/2" hex head bolt
COMPONENT DESCRIPTION
3/8" lock washer s.s.
3/8" x 2-3/4"
wedge anchor w/nut & flat washer s.s.
gray protective cap
3/8" x 3-1/2"
wedge anchor w/nut & flat washer s.s.
COMPONENT DESCRIPTION
5/16" x 2" all-thread stud s.s.
5/16" x 2-1/2" all-thread stud s.s.
5/16" flat washer s.s.
5/16" hex flange nut s.s.
gray protective cap
20
X - S T R E A M 2 ™ S L I D E
