- Page 1 S K E T B L L S E T ssembly & Installation Instructions 3 0 5 0 L V E R N O N • T U C S O N , 8 5 7 1 3 5 2 0 . 7 9 0 . 7 0 4 0 •...
-
Page 2: Table Of Contents
T BLE OF CONTENTS: Intended Use Instructions ............1 In Deck/In Ground Installation..........2-4 On Deck Installation ..............5-7 Backboard Exploded View ............8 Inter-Fab Limited Warranty............9 LIST OF REQUIRED TOOLS Tools required for assembly and installation of Basketball Set: NOTE: USE PROVIDED NTI-SEIZE ON... -
Page 3: Intended Use Instructions
INST LL TION INSTRUCTIONS B SKETB LL - 18” SETB CK INTENDED USE INSTRUCTIONS 1. Everyone who uses this Water Sports™ game set must know, understand and follow these instructions 2. This game set is designed for residential in ground pool use only. This game set may not be used on any above ground pool. -
Page 4: In Deck/In Ground Installation
INST LL TION INSTRUCTIONS B SKETB LL - 18” SETB CK IN DECK INST LL TION REQUIREMENTS: To complete an in deck/in ground basketball game set installation, you will need Box #1, Box #2, and Box #4 OR Box #5 to fulfill the necessary parts required. B-Ball Box #1 (backboard) Includes backboard, rim, net, basketball, pump and rim to backboard hardware. - Page 5 INST LL TION INSTRUCTIONS B SKETB LL - 18” SETB CK STEP ONE: Basketball poles must be anchored into deck with either the bronze 6” anchor jig (welded @ 16” on center) or the plastic anchor jig (glued @ 16” on center). Position the anchor 18” back from edge of the pool (as shown in Fig.
- Page 6 INST LL TION INSTRUCTIONS B SKETB LL - 18” SETB CK Fig. 11 Fig. 12 Support Poles ffixed to Threaded Insert Nuts Backboard Hardware Kit STEP FOUR: (Requires hardware from B-Ball box #1 - See Fig. 12) Pass 3/8” x 5” T bolt through back side of Slam Jam bracket.
-
Page 7: On Deck Installation
INST LL TION INSTRUCTIONS B SKETB LL - 18” SETB CK ON DECK INST LL TION REQUIREMENTS: To complete an on deck/above ground basketball game set installation, you will need Box #1 and Box #3. B-Ball Box #1 (backboard) Includes backboard, rim, net, basketball, pump and rim to backboard hardware. B-Ball Box #3 (on deck pole set) Includes 2 on deck poles, 2 (two) 9”... - Page 8 INST LL TION INSTRUCTIONS B SKETB LL - 18” SETB CK STEP TWO: ttach the cross brace to the support posts (See Fig. 18) by inserting the cross brace inside the 2 support post stubs (See Fig. 19). The square 4 hole plate on the cross brace faces the pool. Insert the two (2) 3/8”...
- Page 9 INST LL TION INSTRUCTIONS B SKETB LL - 18” SETB CK Fig. 24 Fig. 25 T Bolt and Slam Jam Bracket Shown Rim Installation Shown STEP SIX: Place an escutcheon on each deck pole bottom, ensuring that the escutcheon is oriented correctly. Insert a deck anchor into the bottom of each deck pole bottom.
-
Page 10: Backboard Exploded View
INST LL TION INSTRUCTIONS B SKETB LL - 18” SETB CK Fig. 28 Fig. 29 Hardware Kit WS-DM Shown On Deck nchors, Escutcheons, Hardware Fig. 30 Exploded View of ll Parts for Basketball Set B-Ball-18-IM Rev. 2/12 (WS-BK B B LL18) -
Page 11: Inter-Fab Limited Warranty
Inter-Fab, Inc., and expressly does not cover any labor or reinstallation expenses related to the replacement of any and all Inter-Fab products. This limited warranty shall be the sole and exclusive remedy of irrespective of whether the claims are made in contract, tort, warranty, law, equity or by statue.
