- Page 1 1 5 ’ G A R D E N R I D E S L I D E Assembly & Installation Instructions ATTENTION INSTALLERS: THESE INSTRUCTIONS MUST REMAIN WITH THE SLIDE OWNER! PLEASE DELIVER AND REVIEW THIS MANUAL WITH THE HOMEOWNER. 15’...
- Page 2 W RNING WARNING: IMPORTANT INSTALLATION INFORMATION The installation of this product should be done only by a licensed and professional installer. Installation should be done strictly in conformance with all local building codes, electrical codes and other building and safety laws and regulations. Among other things, that your installer should carefully analyze the need to bond the product to prevent an electrical hazard.
-
Page 3: Table Of Contents
I N S T A L L A T I O N I N S T R U C T I O N S 1 5 ’ G R S S L I D E TABLE OF CONTENTS: Intended Use Instructions ............2 Water Safety Envelope.............3 Slide Placement/Deck Requirements ........4-5 Slide Measurements ...............6... -
Page 4: Intended Use Instructions
W RNING I N S T A L L A T I O N I N S T R U C T I O N S 1 5 ’ G R S S L I D E INTENDED USE INSTRUCTIONS Everyone who uses this slide must know, understand and follow these instructions The ANSI/APSP/ICC-5 2011 standard for above ground pools prohibits the use of slides or diving boards on above ground pools. -
Page 5: Water Safety Envelope
I N S T A L L A T I O N I N S T R U C T I O N S 1 5 ’ G R S S L I D E WATER SAFETY ENVELOPE: A minimum water depth of three feet (3') under the exit of the slide which increases to a depth of four feet six DIAGRAM A inches (4'6”) at point A which is located four feet six... -
Page 6: Slide Placement/Deck Requirements
I N S T A L L A T I O N I N S T R U C T I O N S 1 5 ’ G R S S L I D E SLIDE PLACEMENT If the slide meets the pool edge at an angle, then the outside curve “Pivot A” has to be at the pool edge. - Page 7 I N S T A L L A T I O N I N S T R U C T I O N S 1 5 ’ G R S S L I D E MINIMUM DECK REQUIREMENTS DIAGRAM G (NOT TO SCALE) GRS 15’...
-
Page 8: Slide Measurements
I N S T A L L A T I O N I N S T R U C T I O N S 1 5 ’ G R S S L I D E MEASUREMENTS: 15’ GRS LEFT TURN LEFT TURN WITH SUPPORTS LEFT TURN WITHOUT SUPPORTS LEFT TURN HEIGHT... -
Page 9: Slide Components
I N S T A L L A T I O N I N S T R U C T I O N S 1 5 ’ G R S S L I D E SLIDE COMPONENTS: ANCHOR COMPONENTS: 15’ arden Ride Slide Series 15’... -
Page 10: Installing Landing Pads
I N S T A L L A T I O N I N S T R U C T I O N S 1 5 ’ G R S S L I D E 15’ GARDEN RIDE SLIDE ASSEMBLY INSTALLING LANDING PADS: Using cardboard to place under the slide sections so as not to damage the finish;... -
Page 11: Connecting Handrails
I N S T A L L A T I O N I N S T R U C T I O N S 1 5 ’ G R S S L I D E CONNECTING HANDRAILS: Install the handrails (See Figure 5) for the correct orientation, use the provided 3/8” x 1” stainless steel bolt, flat washer and lock washer to attach - do not over tighten. -
Page 12: Attach Leg Supports To Landing Pads
I N S T A L L A T I O N I N S T R U C T I O N S 1 5 ’ G R S S L I D E ATTACH LEG SUPPORTS TO LANDING PADS: While the slide is still upside down, you may attach the short legs to the Exit Section Landing Pad which is pre-drilled to accept the bracket. -
Page 13: On-Deck Installation
I N S T A L L A T I O N I N S T R U C T I O N S 1 5 ’ G R S S L I D E Once placement has been determined, starting from the Exit Section, align leg supports using a bubble level ensure both legs are straight (plumb). -
Page 14: In-Deck Installation
I N S T A L L A T I O N I N S T R U C T I O N S 1 5 ’ G R S S L I D E IN-DECK INSTALLATION: Attach slide legs to the higher of the 2 bolt holes on the deck anchor “hole B”, make a mark with a marking pen or duct tape 4 ⁄... -
Page 15: Slide Care & Maintenance
I N S T A L L A T I O N I N S T R U C T I O N S 1 5 ’ G R S S L I D E GARDEN RIDE SERIES SLIDE CARE & MAINTENANCE: Your Garden Ride slide requires periodic maintenance to keep it looking like new and protected from the elements. -
Page 16: S.r.smith Limited Warranty
S . R . S M I T H L I M I T E D W A R R A N T Y 3050 S. ALVERNON WAY • TUCSON, AZ 85713 520.790.7040 • 800.737.5386 • FAX 520.790.7127 • INTERFAB.COM GRS15-IM Rev.
