T H E C I T Y 2 S L I D E
Assembly & Installation Instructions
Visit inter-fab.com to view our installation help video.
(Video does NOT replace installation instructions.)
WARNING: IMPORTANT INSTALLATION INFORMATION
The installation of this product should be done only by a licensed and professional installer. Installation should
be done strictly in conformance with all local building codes, electrical codes and other building and safety laws
and regulations. Among other things, that your installer should carefully analyze the need to bond the product
to prevent an electrical hazard. Failure to properly install this product could result in a dangerous condition,
including but not limited to electrical or structural hazards. Inter-Fab, Inc. disclaims all liability arising from the
installation and the user assumes all risk associated with the installation.
I N T E R - F A B , I N C . 3 0 5 0 S . A L V E R N O N W AY • T U C S O N , A Z 8 5 7 1 3
5 2 0 . 7 9 0 . 7 0 4 0 • 8 0 0 . 7 3 7 . 5 3 8 6 • F A X 5 2 0 . 7 9 0 . 7 1 2 7 • i n t e r - f a b . c o m
Rev. 7/15 (SBK-CITY2 INSTL)
IMPORTANT
These
instructions
must remain
with the
slide owner!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the The city 2 slide and is the answer not in the manual?

Questions and answers

Summary of Contents for Inter-fab The city 2 slide

  • Page 1 Failure to properly install this product could result in a dangerous condition, including but not limited to electrical or structural hazards. Inter-Fab, Inc. disclaims all liability arising from the installation and the user assumes all risk associated with the installation.
  • Page 2: Table Of Contents

    Step 5 ..................9 Inspection Check List.............10 Slide Care & Maintenance............10 Paver Kit Information ............11-12 Exploded View of City 2 Slide ..........13 Parts List (corresponds with exploded view)......14 Hardware Parts List..............15 Pages for Notes ..............16-17 Inter-Fab Limited Warranty.............18 Rev. 7/15 (SBK-CITY2 INSTL)
  • Page 3: Intended Use Instructions

    I N S T A L L A T I O N M A N U A L C I T Y 2 S L I D E ™ INTENDED USE INSTRUCTIONS Everyone who uses this slide must know, understand and follow these instructions. The ANSI/NSPI-4 2007 standard for above ground pools prohibits the use of slides or diving boards on above ground pools.
  • Page 4: Water Safety Envelope

    I N S T A L L A T I O N M A N U A L C I T Y 2 S L I D E ™ DIAGRAM A WATER SAFETY ENVELOPE: (NOT TO SCALE) A minimum water depth of three feet (3') under the exit of the slide which increases to a depth of four feet (4') at point A which is located four feet six inches (4'6") from the back wall of the pool.
  • Page 5: Slide Footprint Diagrams

    I N S T A L L A T I O N M A N U A L C I T Y 2 S L I D E ™ SLIDE FOOTPRINT DIAGRAMS DIAGRAM D – RIGHT TURN SLIDE RECOMMENDED MIN. DECK AREA: 12’...
  • Page 6 I N S T A L L A T I O N M A N U A L C I T Y 2 S L I D E ™ SLIDE & WATER STUB-UP PLACEMENT DIAGRAMS DIAGRAM F - City 2 Slide - Left Turn (NOT TO SCALE) 3”...
  • Page 7: Step

    I N S T A L L A T I O N M A N U A L C I T Y 2 S L I D E ™ STEP ONE: FLUME ASSEMBLY Open box and remove slide components and parts pack.
  • Page 8: Step 1

    I N S T A L L A T I O N M A N U A L C I T Y 2 S L I D E ™ STEP 1 Pre-assemble wedge, round-to-flat connector and carriage bolt as shown. STEP 2 Insert assembly into handrails as shown, until shoulder portion of connector seats against end of tubing, tap...
  • Page 9 1 self tapping screw through each leg (approx. 1" below WILL BE AN IN-DECK OR ON-DECK INSTALLATION. the top of the leg) into the leg spud; otherwise, move the INTER-FAB CANNOT/DOES NOT GUARANTEE THE legs in relation to the spuds until proper leveling is obtained CUSTOMER’S CONCRETE DECK.
  • Page 10: Step

    I N S T A L L A T I O N M A N U A L C I T Y 2 S L I D E ™ STEP FIVE: CONNECTING THE WATER SUPPLY Feed the 1/2” diameter flex hose (provided) through the slots on the right side of the slide ladder.
  • Page 11: Inspection Check List

    I N S T A L L A T I O N M A N U A L C I T Y 2 S L I D E ™ FINAL INSPECTION CHECK LIST: 1. INSPECT THE SLIDE FLUMES FOR ANY VISIBLE DAMAGE, CRACKS, OR TEARS. 2.
  • Page 12 PAVER KIT INFO – CITY 2 SLIDE When installing an Inter-Fab City 2™ slide using a paver kit, you must ensure that all standard installation requirements are met. The slide must be compatible with the type of pool on the intended installation and all ANSI/APSP/ICC-5 2011 requirements must be met.
  • Page 13 You will need a 3/8” masonry bit and a 1/2” regular bit for the City 2™ slide. Inter-Fab Inc. will not be responsible for damage to pavers caused by drilling or mechanically attaching to concrete pad. Refer to paver manufacturer’s specific installation instructions before beginning.
  • Page 14 I N S T A L L A T I O N M A N U A L C I T Y 2 S L I D E ™ ITY 2™ SLIDE ( ITY2- LW) Rev. 7/15 (SBK-CITY2 INSTL)
  • Page 15 I N S T A L L A T I O N M A N U A L C I T Y 2 S L I D E ™ CITY 2™ SLIDE (CITY2-CLW) ALL CHART INFORMATION BELOW CORRESPONDS WITH THE DRAWING ON THE PREVIOUS PAGE. <--- DR WING REPRESENTS THE FOLLOWING P RT NUMBERS: CITY2-CL (shown)
  • Page 16: Parts List (Corresponds With Exploded View)

    I N S T A L L A T I O N M A N U A L C I T Y 2 S L I D E ™ PARTS LIST: CS-101-SS – LEG AND HANDRAIL HARDWARE QTY COMPONENT DESCRIPTION 1/4”...
  • Page 17 I N S T A L L A T I O N M A N U A L C I T Y 2 S L I D E ™ NOTES: Rev. 7/15 (SBK-CITY2 INSTL)
  • Page 18 I N S T A L L A T I O N M A N U A L C I T Y 2 S L I D E ™ NOTES: Rev. 7/15 (SBK-CITY2 INSTL)
  • Page 19: Inter-Fab Limited Warranty

    Inter-Fab, Inc., and expressly does not cover any labor or reinstallation expenses related to the replacement of any and all Inter-Fab products. This limited warranty shall be the sole and exclusive remedy of irrespective of whether the claims are made in contract, tort, warranty, law, equity or by statue.
