PART IDENTIFICATION CHART—

Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST on pages 39 and 40. Note: Some small parts may have
been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached. If a part is
missing, call toll-free 1-877-992-5999.
M8 Nylon
Locknut (78)
M8 Washer (103)
M4 x 12mm
M4 x 16mm
Self-tapping Self-tapping
Screw (102) Screw (110)
M8 x 22mm
Shoulder Bolt (90)
M10 Nylon
Locknut (77)
M10 Washer (80)
M6 x 16mm
Screw (88)
5
Model No. 831.14623.0
M12 Nut (112)
M10 Large Washer (105)
M10 x 75mm Button Screw (118)
M10 x 100mm Bolt (140)
R0606A
M4 Washer
(104)
M6 Washer
(114)
M12 Large Washer (98)
