- Page 1 R7050 Photo Tachometer Instruction Manual REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com...
-
Page 2: Table Of Contents
Product Disposal and Recycling ..............8 Product Support ..................8 Introduction Thank you for purchasing your REED R7050 Photo Tachometer. Please read the following instructions carefully before using your instrument. By following the steps outlined in this manual your meter will provide years of reliable service. -
Page 3: Product Quality
CLASS 3R LASER PRODUCT authorized service center. EN60825-1:2007 • Use extreme caution when the laser beam is turned on. • Do not let the beam enter your eye, another person's eye or the eye of an animal. • Be careful not to point the beam off a reflective surface and strike your eye. Features • Provides fast and accurate RPM measurements of rotating objects without contact and revolution count of moving objects • Built-in laser pointer identifies target area • Durable double molded plastic housing and backlit LCD display • Internal memory recalls maximum, minimum values as well as last value stored • Low battery indicator and auto shut-off continued... REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 4: Included
General Specifications Visible Indicator: Yes (Laser) Target Distance: 1.6' (500mm) Response Time: <1 second Sampling Time: 0.5 sec (over 120 RPM) Display Size/Type: 5 Digit LCD Display Backlit Display: Auto Shut-off: Yes (after 10 seconds) Internal Memory: Max, Min and Last Laser Class: Class III Low Battery Indicator: Power Supply: 9V Battery Product Certifications: Operating Temperature: 32 to 122°F (0 to 50°C) Storage Temperature: -4 to 140°F (-20 to 60°C) Operating Humidity Range: 10 to 90% Dimensions: 6.3 x 2.3 x 1.5" (160 x 58 x 39mm) Weight: 5.3oz (151g) REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 5: Instrument Description
Instrument Description 1. Photo Tachometer Laser Sensor 2. Power Adapter Input 3. Mode Button MEAS 4. Memory Button 5. Measurement Button R7050 Tachometer Operating Instructions Counter Applying Reflective Marking Tape Cut and peel the reflective tape provided into approximately 0.5" (12mm) squares. Apply one square to the surface of the object being measured. The non-reflective area must always be greater than the reflective area. If the shaft or rotating object is normally reflective, it must be covered with black tape or black paint before attaching reflective tape. The surface of the object being measured must be clean and smooth before applying the reflective tape. RPM Measurement Mode Apply a small piece of reflective tape to the object being measured (see Applying Reflective Marking Tape section for details). -
Page 6: Count Measurement Mode
Remove the Phillips screw on the back of the meter. Remove the battery cover. Replace the 9V battery. Secure the battery cover back into place and tighten the screw. REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 7: Applications
REED Instruments guarantees this instrument to be free of defects in material or workmanship for a period of one (1) year from date of shipment. During the warranty period, REED Instruments will repair or replace, at no charge, products or parts of a product that proves to be defective because of improper material or workmanship, under normal use and maintenance. -
Page 8: Product Disposal And Recycling
Product Support If you have any questions on your product, please contact your authorized REED distributor or REED Instruments Customer Service by phone at 1-877-849-2127 or by email at info@reedinstruments.com. Please visit www.REEDINSTRUMENTS.com for the most up-to-date manuals, datasheets, product guides and software. - Page 9 TesT & MeasuRe wITh ConfIdenCe CheCk ouT ouR laTesT PRoduCTs! REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com...
- Page 10 REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com...
