3M ScanEM-EQC Probe
™
The tip at the end of the ScanEM-EQC Probe is its antenna. Point it at the
suspected area and keep it close to the measured spot without making contact.
3M ScanEM-HQC Probe
™
Hold the ScanEM-HQC Probe in such a way that the cable that you are testing
fits into the groove of the ScanEM-HQC Probe's antenna.

Stand-Alone Operation

In the stand-alone mode the ScanEM-QC Probe is completely self-sufficient
and requires nothing else to operate.

Quick Set-Up

Hold the ScanEM-QC Probe in the palm of your right hand as if you were
holding a pen
‰ Set the Sound switch in the desired position (if in doubt, set it to On).
‰ Press the red Operate button with your thumb and hold it down.
‰ Point the ScanEM-QC Probe's antenna away from the tested product.
‰ With your index finger, adjust the Level dial so only the green LED is On.
‰ Position the ScanEM-QC Probe perpendicular to the tested area and bring
its antenna as close as possible without actually touching the tested product.
With ScanEM-HQC Probe, set the cable into the groove of its antenna.
‰ Move the ScanEM-EQC Probe around the tested product or area or along the
cable (ScanEM-HQC Probe) and observe changes in sound and LED output.
The closer the ScanEM-EQC Probe's antenna is to the tested area, the greater
its spatial resolution. A scan performed an inch or two away from the product
can direct you to the general area where high emissions are generated, but the
precise location of the source can be found only when the antenna is in close
proximity to the product.
