3M SCOTT SEMS II PRO Operation And Maintenance Instructions

Wireless scba telemetry system for the air-pak x3 pro scba
Hide thumbs
Table of Contents

Advertisement

Quick Links

WIRELESS SCBA TELEMETRY SYSTEM
SEMS II PRO CONSOLE
THE SEMS II PRO WIRELESS SCBA TELEMETRY SYSTEM IS INTENDED FOR USE WITH 3M SCOTT SELF-CONTAINED
BREATHING APPARATUS (SCBA), WHICH MAY SUPPORT HUMAN LIFE IN HAZARDOUS ATMOSPHERES. FAILURE TO
CAREFULLY READ AND UNDERSTAND THE FOLLOWING INSTRUCTIONS MAY RESULT IN SERIOUS INJURY OR DEATH
TO THE SCBA USER.
USE OF A RESPIRATOR INTEGRATED WITH THE SEMS II PRO WIRELESS SCBA TELEMETRY SYSTEM WILL REQUIRE
MODIFICATION OF THE RESPIRATOR "REGULAR OPERATIONAL INSPECTION" PROCEDURES AND WILL REQUIRE
TRAINING OF THE RESPIRATOR USER IN THE USE OF SUCH RESPIRATORS.
THE FOLLOWING INSTRUCTIONS SUPPLEMENT BUT DO NOT REPLACE THE OPERATING AND MAINTENANCE
INSTRUCTIONS SUPPLIED WITH EACH RESPIRATOR.
THIS PRODUCT IS DESIGNED AND INTENDED TO FUNCTION PROPERLY IN REASONABLE/ORDINARY
FIREFIGHTING CONDITIONS. IT HAS BEEN CERTIFIED TO THE STANDARDS CONTAINED IN THE 2018 EDITION
OF NFPA 1982. LIKE ALL EQUIPMENT, THE FUNCTIONALITY OF THIS PRODUCT MAY BE COMPROMISED BY
EXTREME FIRE CONDITIONS.
THESE USER INSTRUCTIONS ARE TO BE REMOVED ONLY BY THE END USER.
OPERATION AND MAINTENANCE INSTRUCTIONS
SEMS II PRO
FOR THE 3M™ SCOTT™ AIR-PAK™ X3 PRO SCBA
SEMS II GATEWAY
SEMS II REPEATER
WARNING
WARNING
NOTICE:
Page 1 of 28
SEMS II PRO CONSOLE ON
3M SCOTT AIR-PAK X3 PRO
SCBA
P/N 595369-01 Rev B 07/19

Advertisement

Table of Contents
loading

Related Manuals for 3M SCOTT SEMS II PRO

Summary of Contents for 3M SCOTT SEMS II PRO

  • Page 1 SEMS II REPEATER WARNING THE SEMS II PRO WIRELESS SCBA TELEMETRY SYSTEM IS INTENDED FOR USE WITH 3M SCOTT SELF-CONTAINED BREATHING APPARATUS (SCBA), WHICH MAY SUPPORT HUMAN LIFE IN HAZARDOUS ATMOSPHERES. FAILURE TO CAREFULLY READ AND UNDERSTAND THE FOLLOWING INSTRUCTIONS MAY RESULT IN SERIOUS INJURY OR DEATH TO THE SCBA USER.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ................................... 3 SEMS II PRO OVERVIEW ................................3 SEMS II PRO COMPONENTS ..............................4 SEMS II PRO CONTROL CONSOLE ................................4 SCOTT CONNECT MONITOR SYSTEM SOFTWARE ............................. 5 PAK-TRACKER LOCATOR SYSTEM ................................5 RFID PROGRAMMER ...................................... 6 USING THE PASS DEVICE ................................

  • Page 3: Introduction

    This system communicates only with Firefighter Resources (Respirator Users) RESPIRATOR. using a 3M Scott Air-Pak X3 Pro SCBA equipped with the integrated SEMS II Pro. Complete training in the use of the SEMS II Pro equipment is required before actual use in a hazardous environment.

  • Page 4: Sems Ii Pro Components

    SEMS II PRO COMPONENTS SEMS II Pro, when added to a 3M Scott Fire & Safety SCBA, consists of a Sensor Module assembly with a battery compartment mounted to the bottom of the respirator backframe, a pressure gauge with transducer, and a Control Console mounted on the wearer’s right shoulder strap at the pressure gauge location.

  • Page 5: Scott Connect Monitor System Software

    CONNECT MONITOR software (Monitor) is designed to provide incident commanders or other responsible parties with critical, real-time information about the 3M Scott Air-Pak X3 Pro SCBA in use on an emergency scene. The application uses the mesh network created by the SEMS II and SEMS II Pro-equipped SCBAs to receive and display air level and alarm information for all SCBA users on a scene.

  • Page 6: Rfid Programmer

    200734). DO NOT USE AN RFID TAG READER THAT HAS 3M recommends re-programming with the RFID card in accordance with your AN OUTPUT POWER GREATER THAN 6 WATTS organization's procedures to ensure that the user's unique ID number is in use at all WHILE IN A FLAMMABLE ATMOSPHERE.

  • Page 7: Using The Pass Device

    USING THE PASS DEVICE ACTIVATION WARNING THE INFORMATION BELOW IS MEANT TO Prepare the respirator for use according to the user instructions provided with SUPPLEMENT, NOT REPLACE, THE TRAINING, the respirator. Install the batteries in the PASS device according to the BATTERY S U P E R V I S I O N , M A I N T E N A N C E , A N D INSTALLATION section of this instruction.

  • Page 8: Pre Alarm

    PRE ALARM If the respirator remains motionless for more than twenty (20) seconds, the PASS device will automatically sound a pre-alarm. When the pre-alarm occurs, the green flashing light on the Control Console is replaced by alternating bright red lights which flash approximately once per second and are accompanied by an ascending/descending audible tone that increases in volume during the pre-alarm cycle.

  • Page 9: Low Battery

    Edition. The PASS device includes on-board electronics which maintain a running PAK-ID FOR 24 HOURS. IF THE SCBA IS USED log of event data including start-up, shut-down, and PASS activation. The 3M Scott WITHIN 24 HOURS OF PROGRAMMING WITH Pak-Link Programmer (P/N 200672-01) and Configure are required to access the AN RFID TAG, BADGE, OR BUTTON, THE NEW information.

  • Page 10: Using The Sems Ii Pro Wireless Scba Telemetry System

    SEMS II PRO COMMUNICATES ONLY WITH FIREFIGHTER RESOURCES (RESPIRATOR CONSOLE DISPLAY USERS) USING A 3M SCOTT FIRE & SAFETY SCBA EQUIPPED WITH THE SEMS II & SEMS The console display has four (4) icons that light in response to specific conditions:...

  • Page 11: Programming A Pass Device With An Rfid Tag

    PROGRAMMING A PASS DEVICE WITH AN RFID TAG 3M recommends re-programming the PASS device with the RFID card in accordance with your organization's procedures to assure that the user's unique ID number is in use at all times. To program the identification of a PASS device with an RFID Tag, proceed as follows: Verify that the air cylinder is closed and there is no residual air in the system.

  • Page 12: Operation And Use Of Sems Ii Pro Console Units

    OPERATION AND USE OF SEMS II PRO CONSOLE UNITS Users of 3M Scott Air-Pak X3 Pro SCBAs equipped with the SEMS II Pro Control Consoles must be fully trained in the operation of the equipment as part of a complete respiratory protection program before entering a hazardous environment.

  • Page 13: Base Station Operation

    OCCUR, WHICH COULD RESULT IN SERIOUS The SEMS II Pro Base Station consists of Monitor installed in a Windows based INJURY OR DEATH. Personal Computer, preferably a laptop (not included). 3M recommends the use of a laptop computer designed for rugged use. WARNING...
  • Page 14 – WITHDRAW Notification - A user chooses to WITHDRAW by pressing the gray button on the SEMS II Pro Control Console on the SCBA. When this occurs, the WITHDRAW request is sent to the Base Station, which displays "Withdraw Requested" and sounds the WITHDRAW audible alarm.

  • Page 15: Regular Operational Inspection

    WARNING Inspect and test the PASS device, SEMS II Pro Wireless SCBA Telemetry System, and the Locator System along with the inspection and test of the 3M Scott Air- FOLLOW THE REGULAR OPERATIONAL Pak X3 Pro SCBA respirator before each use. Refer to the PAK-TRACKER User INSPECTION PROCEDURE EXACTLY.
  • Page 16 WARNING 10. After the pre-alarm condition occurs, check the pre-alarm reset. Within twelve (12) seconds of the pre-alarm, move the respirator to activate the motion FOLLOW REGULAR OPERATIONAL INSPECTION sensor. The PASS device resets to sensing mode. The red flashing light is PROCEDURE EXACTLY.

  • Page 17: Operation Of Sensor Module Lights

    OPERATION OF SENSOR MODULE LIGHTS When performing the REGULAR OPERATIONAL INSPECTION verify that the Sensor Module lights are operating as described below: ACTION OR SITUATION BEHAVIOR OF LIGHTS Start Air-Pak SCBA (i.e., open cylinder valve) Bright light, then flashing green light Normal operation Flashing green light Air cylinder between 1/2 and 1/3 full...

  • Page 18: Cleaning, Maintenance And Storage

    REPLACEMENT PARTS AND SERVICE The PASS device is covered by a one year warranty. Consult your authorized 3M Scott representative, distributor or service center as to the availability of service and parts for the PASS device. Replacement batteries of the type designated are commercially available over the counter, from your authorized distributor, and from most industrial battery distributors.

  • Page 19: Battery Replacement

    WARNING THE PASS DEVICE IS INTENDED TO ASSIST A 3M Scott Air-Pak X3 Pro SCBA equipped with a PASS device require six (6) “AA” IN LOCATING A PERSON WHO MAY BE IN A cell batteries for operation. The six (6) batteries power the Heads-Up Display, the LIFE-THREATENING SITUATION.
  • Page 20 The battery cover must be installed so that it is water-tight after replacement. Clean the sealing rib around battery compartment and sealing face of the cover CAUTION by wiping with a clean damp cloth to remove any dirt or foreign matter that IMPROPER BATTERY COVER INSTALLATION might prevent a proper seal.

  • Page 21: Detecting And Avoiding Radio Frequency Interference

    DETECTING AND AVOIDING RADIO FREQUENCY INTERFERENCE When any electronic device is adversely affected by radio waves, radio frequency interference (RFI) is said to have occurred. All electronic devices like the PASS device WARNING may be subject to the effects of RFI. Radio transmissions from the antennas of radios K E E P T H E A N T E N N A S O F H A N D - H E L D including those used by fire fighters, police, and other public safety related personnel RADIOS AT LEAST SIX (6) INCHES AWAY...

  • Page 22: Rfi And The Pak-Tracker Hand Held Receiver

    In a known safe, non-hazardous area, remove and reinstall the batteries to reset the unit (see the BATTERY REPLACEMENT section of the Locator System User Instructions, 3M Scott P/N 595278-01). Then inspect and return the HHR to service. RETROFITTED UNITS Installation of SEMS II Pro requires some disassembly of the respirator and should only be performed by an authorized service center.

  • Page 23: Safety Listings

    SAFETY LISTINGS FCC COMPLIANCE FCC Compliance Statement (Part 15.19) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: WARNING This device may not cause harmful interference, and RADIO FREQUENCY INTERFERENCE (RFI) This device must accept any interference received, including interference that MAY CAUSE A MALFUNCTION OF THE PASS may cause undesired operation.

  • Page 24: Radio Frequency Interference (Rfi)

    RFI, most of which are temporary in nature. WITH A PASS DEVICE MUST BE AWARE OF Users of the 3M Scott Air-Pak X3 Pro SCBA with PASS device must be familiar with THE PROPER OPERATION OF THE DEVICE.

  • Page 25: Sems Ii Pro Integrated Pass Device Performance Specifications

    Full Alarm (red flashing light, 95 dBA sound)....Approx. 8 hours Compliance The PASS device is a NIOSH approved accessory for use on only the following 3M Scott Fire & Safety SCBAs: 3M SCOTT AIR-PAK X3 PRO SCBA - SNAP-CHANGE & CGA 2.2 (30 MIN.)

  • Page 26: Quick Reference Guide

    WARNING READ AND UNDERSTAND THE COMPLETE INSTRUCTION MANUAL BEFORE USING A RESPIRATOR WITH A PASS DEVICE INSTALLED. QUICK REFERENCE GUIDE WHEN YOU WANT TO... YOU DO... THE PASS DEVICE DOES... Turn it on. Open cylinder valve (cylinder 3 quick audible chirps, green must have air in it).
  • Page 27 P/N 595369-01 Rev B 07/19 Page 27 of 28...
  • Page 28 LIMITED WARRANTY ON NFPA 1981 AND NFPA 1982, 2018 COMPLIANT AIR-PAK SCBA PRODUCTS 3M Scott Fire & Safety (3M Scott) warrants NFPA 1981 and NFPA 1982, 2018 Compliant AIR-PAK SCBA PRODUCTS (THE PRODUCTS) to be free from defects in workmanship and materials for a period of ten (10) years from the date of original manufacture by 3M Scott.
