Summary of Contents for evoheat Evo270
-
Page 2: Table Of Contents
EvoHeat Evo270 Hot Water Heat Pump Manual Contents 1. Introduction _________________________________________________________________________________ 2 2. Safety Precautions ____________________________________________________________________________ 2 3. How it Works ________________________________________________________________________________ 3 4. Unit Dimensions & Technical Data ________________________________________________________________ 3 5. Installation __________________________________________________________________________________ 4 5.1 Pipeline Connection Diagram _________________________________________________________________ 4 5.2 Recommended Household Size _______________________________________________________________ 4... -
Page 3: Introduction
Fingers and objects must not be placed into the fan of the unit. Children should be kept clear of the appliance. In the event of the unit malfunctioning, shut off the power supply and contact your supplier or EvoHeat. Power the unit off during cleaning. -
Page 4: How It Works
EvoHeat Evo270 Hot Water Heat Pump Manual 3. How it Works System Principle: Refrigerant is compressed into vapor with high temperature and high pressure when it goes through the compressor. On the discharge side of the compressor, the now hot and... -
Page 5: Installation
EvoHeat Evo270 Hot Water Heat Pump Manual 5. Installation 5.1 Pipeline Connection Diagram Pipeline connection explanation Installation of the water inlet or outlet pipes: The specification of the water inlet and outlet threat is BSP3/4(internal thread). Pipes must be heat-resistant and durable. -
Page 6: Handling & Transportation
EvoHeat Evo270 Hot Water Heat Pump Manual 5.3 Handling & Transportation As a rule, the unit should be stored and/or transported in its shipping container in an upright position and without water charge. For transport over short distances, and provided due care is exercised, an inclination angle of up to 30 degrees is permitted. -
Page 7: Cable Connection
EvoHeat Evo270 Hot Water Heat Pump Manual The Evo 270 is designed for external installation; however, if possible, installing the system under the house eaves or in a sheltered environment may help prolong the life of the system. 1. The unit must be installed, operated and maintained in good order and accordance with these instructions. -
Page 8: Filling The Tank
EvoHeat Evo270 Hot Water Heat Pump Manual 5.5.1 Filling the Tank Open a hot water tap inside the house Open the cold-water inlet valve into the Evo 270 to fill the tank. When water begins flowing out of the hot water tap inside the premises, turn off the hot water tap. -
Page 9: Controller Button Descriptions
EvoHeat Evo270 Hot Water Heat Pump Manual 6.1 Controller Button Descriptions 6.2 Icon Descriptions... -
Page 10: Turning The Unit On & Off
EvoHeat Evo270 Hot Water Heat Pump Manual 6.3 Turning the Unit ON & OFF Press and hold for 0.5 seconds in the standby screen of the controller to turn the unit on. The main display will now show the water outlet temperature. -
Page 11: Target Temperature Checking & Setting
EvoHeat Evo270 Hot Water Heat Pump Manual 6.5 Target Temperature Checking & Setting In the standby or running interface, press once to check the target temperature of the outlet water. Press again to change the target temperature. After making changes to the... -
Page 12: Using The Timer
EvoHeat Evo270 Hot Water Heat Pump Manual 6.7 Using the Timer In heating mode, two running periods can be set. Press and hold for 2 seconds to enter the timer setting menu. Running Period 1: The symbol “ON 1” on the right side of the screen and the time setting will be flashing. Set the time and confirm. - Page 13 EvoHeat Evo270 Hot Water Heat Pump Manual Example Below: Running Period 1: 8:00-10:00 Running Period 2: 16:30-22:00...
-
Page 14: Vacation Mode
EvoHeat Evo270 Hot Water Heat Pump Manual To cancel the timer setting: 6.8 Vacation Mode Press and hold for 2 seconds to enter into the timer setting menu. The symbol “ON” and the date parameters will be flashing. Set the date the same way as in 6.7 Using the Timer. -
Page 15: Hydropower Setting
EvoHeat Evo270 Hot Water Heat Pump Manual 6.9 Hydropower Setting The Hydroboost heater can be turned on when the unit is heating or on standby. Press once to turn on the Hydroboost heater and press again to shut it off. -
Page 16: Adjusting The Hydro Power Booster
To disable the Sanitech feature, simply adjust the Sanitech target temperature (g01) to a figure below the normal water storage temperature (generally 50 degrees or lower). *Changing these settings may lower or disable the Evo270’s ability to ensure your water is free from bacteria. Description... -
Page 17: Maintenance & Repair
It is recommended a major five (5) year service be conducted on the Evo 270. Warning: Servicing of a water heater must only be carried out by qualified EvoHeat personnel. Phone EvoHeat Service on 1300 859 933 for our closest Accredited Service Agent. -
Page 18: Troubleshooting Guide
EvoHeat Evo270 Hot Water Heat Pump Manual 7.1 Troubleshooting Guide Malfunction Display Cause Solution Bottom water temp. failure The water bottom temp. sensor is open or Check or change the water short circuit. bottom temp. sensor Top tank water temp. failure The water top tank temp. -
Page 19: Appendix
EvoHeat Evo270 Hot Water Heat Pump Manual 8. Appendix 8.1 Unit Parameters Definition Default Note Target Temperature Adjustable 8.2 PCB Description... - Page 20 EvoHeat Evo270 Hot Water Heat Pump Manual Symbol The Definition of the Ports OUT1 Output for compressor (220~240VAC) OUT2 Output for electric heater (220~240VAC) OUT3 Output for 4-way valve (220~240VAC) OUT4 Output for the high speed of fan motor (220~240VAC)
-
Page 21: Detailed Parts Overview
EvoHeat Evo270 Hot Water Heat Pump Manual 8.3 Detailed Parts Overview... - Page 22 EvoHeat Evo270 Hot Water Heat Pump Manual Number Material Code Material Name Specification Remark 68016-040052 Water tank 270LD 20000-370006 Transformer for the power 41X26.5F red VH-3 supply 20000-000032 Electric heater 1.5KW 2000-2118 Retainer for capacitor (180 J) Galvanized sheet 0.8/CY 30-35uF...
-
Page 23: Caution
EvoHeat Evo270 Hot Water Heat Pump Manual 8.4 Caution To reduce the risk of excessive pressures and temperatures in this water heater, install temperature and pressure protective equipment required by local codes. A combination temperature and pressure relief valve must be... -
Page 24: Using The Overheating Protector
The overheating protector is used to turn the power off, preventing the hot water from being heated too high. To return the unit to its normal operational status it will have to be re set manually. Please contact EvoHeat for a service if this occurs. -
Page 25: Warranty
EvoHeat Evo270 Hot Water Heat Pump Manual 9. Warranty...
