Page 2: Table Of Contents
Evo315-C Hot Water Heat Pump Manual Contents 1. Introduction ____________________________________________________________________________________________ 2 2. Unit Specifications _______________________________________________________________________________________ 3 2.1 How it Works ________________________________________________________________________________________ 3 2.2 Dimensions _________________________________________________________________________________________ 3 2.3 Technical Data _______________________________________________________________________________________ 4 2.4 System Diagram ______________________________________________________________________________________ 4 3. Safety Instructions _______________________________________________________________________________________ 5 4. -
Page 3: Introduction
This manual and all others are available for download on our website. When installing the Evo315-C, follow all instructions as documented in this manual. Once the installation is complete, check that all connections are secure before the power is turned on. -
Page 4: Unit Specifications
Evo315-C Hot Water Heat Pump Manual 2. Unit Specifications 2.1 How it Works Refrigerant is compressed into vapor with high temperature and high pressure when it goes through the compressor. On the discharge side of the compressor, the now hot and highly pressurized vapor is cooled down through the heat exchange with the water in the tank until it condenses into a high pressure, moderate temperature liquid. -
Page 5: Technical Data
Working Temp Range: Ambient temperature is -5°C to 43°C (Heat Pump) Operating parameters: The range of the operating water pressures: 0.15~0.85MPa Freeze Protection The Evo315-C has a freeze protection system which will protect the unit from damage by preventing ice forming in the waterways in freezing conditions. 2.4 System Diagram... -
Page 6: Safety Instructions
Fingers and objects must not be placed into the fan of the unit. Children should be kept clear of the appliance. In the event of the unit malfunctioning, shut off the power supply and contact your supplier or EvoHeat. -
Page 7: Installation
Evo315-C Hot Water Heat Pump Manual 4. Installation 4.1 Pipeline Connection Note: A pressure releasing valve is to be fitted in the installation. Spec of the P&T Valve: - Pressure: 0.85MP - Temperature: 99 Installation of the water inlet or outlet pipes: The specification of the water inlet and outlet threat is BSP3/4(internal thread). -
Page 8: Handling & Transportation
Evo315-C Hot Water Heat Pump Manual 4.2 Handling & Transportation As a rule, the unit should be stored and/or transported in its shipping container in an upright position and without water charge. For transport over short distances, and provided due care is exercised, an inclination angle of up to 30 degrees is permitted. -
Page 9: Indoor Installation Recommendations
7. This heat pump must be installed by a licensed contractor. Do not attempt to install yourself if you are not qualified. The Evo315-C must be installed to conform to all relevant Australian Standards and Industry Codes including but not limited to: a. -
Page 10: Cable Connection
4.5 Filling the Tank Open a hot water tap inside the house. Open the cold-water inlet valve into the Evo315-C to fill the tank. When water begins flowing out of the hot water tap inside the premises, turn off the hot water tap. -
Page 11: Operation
Evo315-C Hot Water Heat Pump Manual 5. Operation 5.1 Main Controller Interface ICON NAME FUNCTION ON/OFF Turn the unit on or off. Select options to increase values DOWN Select options to decrease values CLOCK Set the clock or the timer. -
Page 12: Functions Of The Controller
Evo315-C Hot Water Heat Pump Manual 5.2 Functions of the Controller 5.2.1 Turning the Unit ON & OFF Press and hold for 0.5 seconds in the standby screen of the controller to turn the unit on. The main display will now show the water outlet temperature. -
Page 13: Target Temperature Checking & Setting
Evo315-C Hot Water Heat Pump Manual 5.2.3 Target Temperature Checking & Setting In the standby or running interface, press once to check the target temperature of the outlet water. Press again to change the target temperature. After making changes to the desired temperature, press... -
Page 14: Setting The Time And Date
Evo315-C Hot Water Heat Pump Manual 5.2.5 Setting the Time and Date In the standby or running interface, press once, the hour digit will flash. Press the to change the hour setting, then press to confirm. Press the to change the minute setting, then press to confirm. -
Page 15: Setting The Timer
Evo315-C Hot Water Heat Pump Manual 5.2.6 Setting the Timer Timer settings can be set in standard mode, economic mode, auto mode and fast heating mode. Note: there are two types of timing settings: touch and button. The unit will run during the lit time periods and stop on the dim areas. -
Page 16: Cancelling The Timer
Evo315-C Hot Water Heat Pump Manual 5.2.7 Cancelling the Timer To cancel a timer once it has been set, hold down the CLOCK button for 2 seconds until the timer display begins flashing (as you would set the timer). Press the POWER button while the timer is flashing to cancel it. -
Page 17: Keyboard Locking
Evo315-C Hot Water Heat Pump Manual 5.2.9 Keyboard Locking Press and hold for 5s to lock the keyboard. To unlock, press and hold for 5s again. 5.2.10 Force Defrosting In the shutdown state, press for 10 seconds to enable the forced defrosting function. The defrosting symbol will light up. -
Page 18: Troubleshooting
Evo315-C Hot Water Heat Pump Manual 6. Troubleshooting 6.1 Parameters Explained Default Meaning Range Details value Hardware parameters 0-Low speed / 2-Solar water The usage of the O05 port pump 0-No output / 2-Solar water High temperature disinfection target temperature... - Page 19 Evo315-C Hot Water Heat Pump Manual Temperature parameters Hot water target temp setting value 38~75 Heating, the lower temp return difference setting 1~20 value Whether enable the electric heater independent 0 / 1 0-Disable / 1-Enable setting value Electric heating temp setting value...
-
Page 20: Error Codes
Evo315-C Hot Water Heat Pump Manual 6.2 Error Codes Malfunction Display Cause Solution Bottom water temp. sensor failure Top tank water temp. sensor failure 1. Check connection between the sensor to the PC board. Ambient temp. sensor failure 2. Check the resistance of the sensor, if the resistance is greater than 500k or less than 100 this means the sensor is broken and will need to be replaced. -
Page 21: Appendix
Evo315-C Hot Water Heat Pump Manual 7. Appendix 7.1 Wiring Diagram & PCB Board... - Page 22 Evo315-C Hot Water Heat Pump Manual Interface No Name Terminal Function Compressor OUT1 Control compressor on/off output Electric heater OUT2 Control electric heater on/off output Four way valve OUT3 Four way valve relay control output port Fan motor high speed...
-
Page 23: Exploded Parts View
Evo315-C Hot Water Heat Pump Manual 7.2 Exploded Parts View Material Code Material name Specification 40000-240061 Bottom foam Foam Φ542 white 38000-220079 Nozzle Decorative Cover Positioning of 38 High 28 PE Tube Head 20000-220165 02 Electric Heating Covers Round 130*37 Flame Retardant ABS+PC Grey... -
Page 24: Earthing Methodology
The overheating protector is used to turn the power off, preventing the water being heated too hot. To return the unit to its normal operational status it will have to be reset manually. Please contact EvoHeat for a service if this occurs. OPERATION DETAILS To access the overheat protector the front dark grey controller panel must be removed. -
Page 25: Maintenance
Evo315-C Hot Water Heat Pump Manual 8. Maintenance Your Evo315-C will operate most efficiently if regularly inspected as part of your home maintenance schedule. MINOR ANNUAL MAINTENANCE It is recommended that the minor maintenance be performed every 12 months by the dwelling occupant. -
Page 26: Warranty
Warranty Registration EvoHeat highly recommend customers to complete their warranty details online to ensure efficient warranty claim processing. To register your warranty, scan our QR Code or head to our website and fill in the Warranty Registration Form: https://evoheat.com.au/warranty-registration/...
