On this page, you will find some important information for the quick and easy operation and setting of the
Timken C-Power centralized multi-point lubricators. The complete operating manual should be read before the
first installation of the Timken C-Power unit and whenever detailed instructions are required. Make sure to
follow the instructions given in the "Safety Instructions" chapter.
1. Assembly of the C-Power LV-unit (refer to chapters 4 and 7)
■
Insert a new battery set into the battery compartment (follow direction of the arrows).
■
On the assembly plate, insert the contact pin in the correct slot for the C-Power LV-unit that you
intend to use (250 cc or 500 cc).
■
Place the C-Power LV-unit inside the cover and remove its plug.
■ Push the C-Power LV-unit into the cover until lubricant comes out of the opening.
■ If necessary, mount the drive unit onto the mounting device and attach it using the three
pre-drilled holes.
■ Place the C-Power LV-unit inside its cover on the drive unit. Make sure that the catch locks in place
and the teeth of C-Power LV-unit and drive unit interlock.
■
Turn the cover clockwise until the bayonet catch locks in place.
2. Starting the C-Power
■ Hold down the ON/OFF/SELECT button until "Remaining Volume" appears in the display and the
green LED starts blinking.
3. Determining the Discharge Period (refer to chapter 6.7)
■
Refer to the manufacturer's guidelines about the lubrication point that you want to lubricate to
determine the required lubricant amount in cubic centimeters (cc) per one hundred hours of operation.
■ Refer to table 3 (chapter 6.7) and locate your required lubrication amount. The table will reflect the
required C-Power LV-unit size, the setting of the discharge period and the setting mode.
4. Setting the Discharge Period (refer to chapter 6.8)
■
Press the MODE/SAVE button until you reach the Configuration Menu.
■ Push the MODE/SAVE button until you reach the desired setting (days, weeks or months).
■
When the display shows the correct setting mode, push the ON/OFF/SELECT button until you reach
the desired discharge period.
5. Save Settings (refer to chapter 6.8)
■
Press the MODE/SAVE button until the display shows "Remaining Volume."
6. Stopping the C-Power unit (refer to chapter 6.6)
■ Press the ON/OFF/SELECT button until the display shows "– –."
