Timken C-POWER Series Operating Manual page 11

c)
■
Push the C-Power LV-unit into the protection cover until lubricant comes out of the opening
(refer to figure 6).
Figure 6
d)
■
Place the C-Power LV-unit, with its protection cover, on the drive unit. Make sure that the catch
locks in place and that the teeth of the C-Power LV-unit and the drive unit interlock (refer to figure 4
and figure 7).
■
Turn the cover clockwise until the bayonet catch locks.
Figure 7
11
