■ To save the changes, press the MODE/SAVE button until the display reverts to the information that was
displayed before you began changing the settings.
Config.
24
Time
Figures in the display are blinking.
Figure 18
■
To check the changes, press the MODE/SAVE button again, until the display switches to the
configuration mode and shows the current settings.
If You Do Not Want to Save the Changes
If you do not want to save the changes that you have made in the configuration menu, press the
ON/OFF/SELECT button until the display shows the symbol "– –" for OFF or the remaining volume of the
C-Power LV unit in % VOL. The original settings remain valid.
Automatic Termination of the Configuration Mode
In the configuration mode, if you do not press a button for ten seconds, the control system automatically
switches back to the previously set mode ("ON" or "OFF") without saving the changes. The original
settings remain valid.
Additional Discharge
With an additional discharge, a lubrication point can be supplied with an additional amount of the
lubricant. For an additional discharge, the lubrication system must be switched on (the display will
show the remaining volume). Press both buttons simultaneously and hold them down (refer to figure 19).
Figure 19 For an additional discharge, press both buttons at the same time and hold them down.
An additional discharge is only possible at temperatures above 32° F (0° C) (figure 20 – ice crystal is not
visible). Each additional discharge reduces the remaining discharge period, as an increased amount of
the lubricant has been supplied. This must be factored into the lubrication and maintenance schedule. A
calculation is possible using the formula from chapter 6.9 and the remaining volume displayed.
The minimum period between two additional discharges is 30 seconds. If you continue to press the
buttons during that period, further additional discharges will follow.
Days
MODE
SAVE
Display shows "– –," if Timken C-Power was previously off.
Display shows ". % Vol.," if Timken C-Power was previously
switched on.
MODE
ON/OFF
SAVE SELECT
– –
