Setting the Discharge Period

The discharge period can be set any time without having to install a new C-Power LV-unit (refer to
figures 15 to 18) and without having to interrupt operation. The Timken C-Power can be switched on
or off, because the system switches back to its original operating status after the changes have been
made. The only difference is the information shown on the display before and after the settings. In the
following example, the lubricator is switched off.
You must hold down the buttons until the indication of the display changes.
■ To reach the configuration menu, hold down the MODE/SAVE button until the display changes.
Then, the lubricator shows the current settings.
Figure 15
■ You can now switch from days to weeks to months within the setting mode by pressing the
MODE/SAVE button.
MODE
SAVE
Figure 16
■
If you have reached the desired setting mode, push the ON/OFF/SELECT button as many times as it
takes to set the number of days, weeks or months.
Config. 01
Time
The figures on the display are blinking and gradually increasing with every push of the button. The example shows the setting of days.
Figure 17
■
When setting the days, you can select a figure between 01 and 30. After 30, the count starts again
with 01.
■
When setting the weeks, you can select a figure between 01 and 24. After 24, the count starts again
with 01.
■ When setting the months, you can select a figure between 01 and 24, depending on the size of the
C-Power LV-unit (refer to table 1) and on the position of the jumper. After 24, the count starts again
with 01.
16
– –
Lubricator is switched off
Config. 01
Time Weeks
The figures on the display are blinking and the setting mode is shown.
Days Config.
MODE
Time
SAVE
Config. 15
MODE
Time
SAVE
The figures on the display are blinking and the
current setting mode is shown (e.g.
Config.
01
MODE
Time
SAVE
02 Days
MODE
SAVE
Days
15
Days).
Months
Config. 30 Days
Time
