C
h
e
c
k
i
n
g
J
u
m
p
C
h
e
c
k
i
n
g
J
u
m
p
This section explains how to set jumpers for correct configuration of the moth-
erboard.
Setting Jumpers
Use the motherboard jumpers to set system configuration options. Jumpers
with more than one pin are numbered. When setting the jumpers, ensure that
the jumper caps are placed on the correct pins.
The illustrations below show a 2-pin jumper.
When the jumper cap is placed on both pins,
the jumper is SHORT. If you remove the
jumper cap, or place the jumper cap on just
one pin, the jumper is OPEN.
Short
Checking Jumper Settings
The following illustration shows the location of the motherboard jumpers. Pin 1
is labeled.
e
r
S
e
t
t
i
n
g
s
e
r
S
e
t
t
i
n
g
s
This illustration shows a 3-pin
jumper. Pins 1 and 2 are SHORT.
Open
17
1 2
3
