This section explains how to set jumpers for correct configura-
tion of the mainboard.
Setting Jumpers
Use the mainboard jumpers to set system configuration op-
tions. Jumpers with more than one pin are numbered. When
setting the jumpers, ensure that the jumper caps are placed
on the correct pins.
Short
1 2
3
p
e
r
S
e
t
t
i
n
g
s
p
e
r
S
e
t
t
i
n
g
s
This illustration shows a 2-pin
jumper. When the jumper cap is
placed on both pins, the jumper is
SHORT. If you remove the jumper
cap, or place the jumper cap on
just one pin, the jumper is OPEN.
Open
This illustration shows a 3-pin
jumper. Pins 1 and 2 are SHORT.
