1. Install the Serial ATA hard disks into the drive bays.
2. Connect one end of the Serial ATA cable to the motherboard's pri-
mary Serial ATA connector (SATA1).
3. Connect the other end of Serial ATA cable to the master Serial ATA
hard disk.
4. Connect one end of the second Serial ATA cable to the mother-
board's secondary Serial ATA connector (SATA2).
5. Connect the other end of Serial ATA cable to the secondary Serial
ATA hard disk.
6. Connect the Serial ATA power cable to the power connector on each
drive.
7. Proceed to section "Entering VIA Tech RAID BIOS Utility" for the next
procedure.

Entering VIA Tech RAID BIOS Utility

1. Boot-up your computer
2. During POST, press <TAB> to enter VIA RAID configuration utility.
The following menu options will appear.
Note: The RAID BIOS information on the setup screen shown is for reference
only. What you see on your screen may not be exactly the same as shown.
On the upper-right side of the screen is the message and legend box. The
keys on the legend box allow you to navigate through the setup menu options.
The message describes the function of each menu item. The following lists the
keys found in the legend box with their corresponding functions.
F1 View Array
↑, ↓
Move to the next item
Enter Confirm the selection
ESC Exit
68
