1
ATX 20-pin power connector
This 20-pin connector connects to an ATX +12V power supply. The power
supply must have at least 1A on the +5V standby lead (+5VSB).
2
CPU socket
Socket 462 surface mount, Zero Insertion Force socket for the AMD K7 Athlon
XP/Sempron/Athlon/Duron Processors.
3
Northbridge Controller
The VIA KT600 host system controller supports AGP 4X and 8X mode,
400/333/266/200MHz Front Side Bus and DDR 400/333/266/200 MHz DRAM
Module
4
DDR DIMM Sockets
These three 184-pi DIMM sockets support up to 3 GB system memory using
unbuffered non-ECC PC3200/2700/2100 DDR DIMMs.
5
Super I/O (ITE 8705F) Controller
This Super I/O provides the commonly used functionality The chipset support a
high performance floppy disk controller, a multi-mode parallel port, one serial
port, a game port, the mouse and keyboard interface.
6
Flash ROM
This 4Mb ROM contains the programmable BIOS program.
7
IDE connectors
Two IDE connectors support Ultra 133/100/66, PIO mode 4 IDE devices, which
support up to 4 IDE devices.
8
Floppy Disk connector
This connector supports the provided floppy drive ribbon cable. One side of the
connector is slotted to prevent incorrect insertion of the floppy disk cable.
9
AGP slot
This Accelerated Graphics Port (AGP) slot supports 1.5V AGP 8X and 3.3V
AGP 4X mode graphics cards for 3D graphical applications.
10
Serial ATA connectors
These two 7 pins connectors support the thin cables for Serial ATA devices.
11
Southbridge controller
®
The VIA
VT8237 integrated peripheral controller supports various I/O functions
including two Serial ATA ports, 2-channel ATA/133 bus master IDE controller,
up to eight USB 2.0 ports, LPC Super I/O interface, AC'97 interface and PCI
2.2 interface.
®
12
VIA
VT6420 Serial ATA controller
This motherboard incorporates the high performance VIA VT6420 IDE RAID
controller, which supports RAID 0 and RAID 1 for a balance of hard disk per-
formance and data protection.
