SATA3/SATA4: Serial ATA connector
These two connectors are t
brid solution that combines two independent SATA ports and one Ultra ATA
port for support of up to two Serial ATA (Serial ATA RAID) and two Ultra ATA
(Ultra ATA RAID) drives. Serial/Ultra ATA RAID function supports striping
(RAID 0) and mirroring (RAID 1). Please note that the function supports hard
disk drives only.
Pin
Signal Name
1
GND
3
TX-
5
RX+
7
GND
he belong VIA VT6420.The
Pin
Signal Name
2
TX+
4
GND
6
RX-
-
-
36
controller is a hy-
