Mandik FDMA Manual

Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading

Related Manuals for Mandik FDMA

Summary of Contents for Mandik FDMA

  • Page 2 These technical specifications state a row of manufactured sizes and models of fire dampers (further only dampers) FDMA. It is valid for production, designing, ordering, delivery, assembly and operation. 1. Description......................... 2. Design..........................3. Communication and control devices..................15 4. Dimensions, weights......................18 5.
  • Page 3 Fire dampers are shutters in ducts of air-conditioning devices that prevent spreading the fire and combustion products from one fire segment to the other one by means of closing the duct in the points of fire separating constructions. Dampers blade automatically closes air duct using a shutting spring or an actuating mechanism back spring.
  • Page 4 Working conditions Right damper function is secured under the following conditions: a) Maximum air circulation speed: 12 m.s Maximum pressure difference: 1200 Pa b) The air circulation in the whole damper section must be secured as steady on whole surface. Operation of the dampers does not depend on the direction of air circulation.
  • Page 5 Design .01 with mechanical control can be complemented with a limit switch signalling of the damper blade position "CLOSED". Limit switch Limit switch „CLOSE“ „CLOSE“ AC 240 V; 3 A Jmenovité napětí, proud DC 250 V; 0,1 A Krytí IP 65 Teplota okolí...
  • Page 6 Nominal voltage AC 230 V / 50 Hz Attraction current 1,2 A Degree of protection IP 40 Ambient temperature -10 °C … +40 °C Connection cable 1m, 3x0,75mm AC 24 V / 50 Hz Nominal voltage DC 24 V Attraction current Degree of protection IP 40 Ambient temperature...
  • Page 7 Design .11 can be complemented with a terminal switch signalling of the damper blade position "OPEN". Limit switch „OPEN“ Limit switch „OPEN“ Limit switch Limit switch „CLOSE“ „CLOSE“ Design .23, or .24 can be complemented with a terminal switch signalling of the damper blade position "OPEN".
  • Page 8 Design with electric actuating mechanism FDMB is always equipped by electric actuating mechanism BFL, BFN, BF 230-T or BFL, BFN, BF 230-T (further only "actuating mechanism"). After being connected to power supply AC/DC 24V or 230V, the actuating mechanism displaces the damper blade into operation position "OPEN"...
  • Page 9 Connection via safety isolating transformer. Parallel connection of other actuators possible. Observe the performance data. Combination of power supply voltage and safety extra-low voltage not permitted at the both auxiliary switches. Application examples for integration into monitoring and control systems or into bus networks can be found in the documentation of the connected communication and power supply unit.
  • Page 10 Nominal voltage AC 24 V 50/60 Hz AC 230 V 50/60 Hz DC 24 V Power consumption - motoring - holding Dimensioning 10 VA (Imax 8,3 A @ 5 ms) 12,5 VA (Imax 500 mA @ 5 ms) Protection class Degree of protection IP 54 Running time - motor...
  • Page 11 Jumper BAE72B-S (BAT) Jumper BAE72B-S (BAT)
  • Page 12 Design with the communication and supply device Design with the communication and supply device BKN 230-24 and the actuating mechanism BF 24-T-ST (BFL 24-T, BFN 24-T). It simplifies electrical wiring and interconnection of fire flap valves. It facilitates on site check and enables central control and checks of fire damper by means of a simple 2-conductor wiring.
  • Page 13 Two conductor wiring to BKS24 BAE72B-S (BAT) Bridge has been installed by the manufacturer. If needed, it can be removed and replaced with a thermoelectrical starting mechanism. If terminals 1 and 2 are not interconnected, safety function is initiated. Bridge can be used only for starting and without BKS 24! Design .61 with communication and supply device can be complemented with smoke detector MHG 231.
  • Page 14 BAE 72TL BAE 72TL Actuating mechanism Actuating mechanism Nominal voltage AC 24 V 50/60Hz DC 24 V Power consumption - motoring - holding Dimensioning 10 VA (Imax 8,3 A @ 5 ms) Protection class Degree of protection IP 54 Running time - motor 140 sec - spring return ~ 16 sec...
  • Page 15 Nominal voltage AC 230 V 50/60Hz Power consumption 14 W (including actuating mechanism) Dimensioning 16 VA (including actuating mechanism) Protection Class Degree of protection IP 40 Ambient temperature - 30 °C … + 50 °C Non-operating temperature - 40 °C … + 80 °C Connection - net cable 1m, with Euro plug - actuator (BF…-Top)
  • Page 16 BKS 24-1B communication and control device is used for control and checks of fire dampers with the BF 24-T-ST (BFL 24-T-ST, BFN 24-T-ST) actuating mechanism in conjunction with the BKN 230-24 supply and communication device. BKS 24-1B receives information about the situation of the fire damper through the BKN 230-24 supply and communication device and issues controlling commands.
  • Page 17 Nominal voltage AC 24 V 50/60Hz Power consumption 2,5 W (operating position) Dimensioning 5 VA Protection Class Degree of protection IP 30 Ambient temperature 0 … + 50 °C 11-pole connector ZSO-11, it is not part of BKS24-1B, Connection ZSO-11 is 11-pole screw terminal 11 x 1,5 mm BKS 24-9A communication and control device is used for group control and checks of 1 to 9 fire dampers with the actuating mechanism BF 24-T-ST (BFL 24-T-ST, BFN 24-T-ST) in connection with the supply and communication device BKN 230-24.
  • Page 19 Rectangular dampers Damper body Damper blade Control lever Shutting spring Base plate Initiation lever Starting mechanism Pawl Thermal protective fuse Inspection hole covering Prestressing rosette Terminal switch Electromagnet (Solenoid) Pulse switch SIEM24 Damper body Damper blade Inspection hole covering Rozeta předepínací BAT thermoelectrical starting mechanism Actuating mechanism...
  • Page 20 Round dampers Damper body Damper blade Control lever Shutting spring Base plate Initiation lever Starting mechanism Pawl Thermal protective fuse Inspection hole covering Prestressing rosette Terminal switch Electromagnet (Solenoid) Pulse switch SIEM24 Damper body Damper blade Inspection hole covering BAT thermoelectrical starting mechanism Actuating mechanism Servopohon...
  • Page 21 Rectangular dampers - dimensions, weights and effective area 10,7 0,0192 50 195 20,0 23,0 0,1169 11,1 0,0224 60 205 20,4 23,4 0,1210 11,6 0,0264 85 230 21,5 24,5 0,1312 10,5 12,2 0,0304 90 235 21,8 24,8 0,1333 11,1 12,8 0,0352 110 255 22,7 25,7...
  • Page 22 13,7 15,4 0,0616 90 235 26,6 29,6 0,2178 14,2 15,9 0,0672 110 255 27,7 30,7 0,2312 14,6 16,3 0,0714 135 280 29,1 32,1 0,2479 15,6 17,3 0,0826 185 330 31,8 34,8 0,2814 16,8 18,5 0,0952 235 380 34,5 37,5 0,3149 - 105 18,0 21,0...
  • Page 23 22,0 23,7 0,1632 185 330 40,9 43,9 0,4536 - 105 23,6 26,6 0,1872 235 380 44,4 47,4 0,5076 - 130 25,3 28,3 0,2112 16,7 19,7 0,0696 10 155 26,9 29,9 0,2352 17,4 20,4 0,0812 15 160 27,2 30,2 0,2400 18,3 21,3 0,0957 35 180...
  • Page 24 - 130 29,7 32,7 0,2772 19,5 22,5 0,0876 10 155 31,6 34,6 0,3087 20,3 23,3 0,1022 15 160 32,0 35,0 0,3150 21,3 24,3 0,1205 35 180 33,5 36,5 0,3402 22,4 25,4 0,1387 50 195 34,7 37,7 0,3591 23,6 26,6 0,1606 60 205 35,4 38,4...
  • Page 25 15 160 40,0 43,0 0,4400 31,4 34,4 0,2030 35 180 41,9 44,9 0,4752 32,8 35,8 0,2337 50 195 43,3 46,3 0,5016 34,6 37,6 0,2706 60 205 44,3 47,3 0,5192 35,8 38,8 0,2952 85 230 46,6 49,6 0,5632 36,7 39,7 0,3137 90 235 47,1 50,1...
  • Page 26 50 195 64,1 67,1 0,8436 47,7 50,7 0,4661 60 205 65,4 68,4 0,8732 51,0 54,0 0,5372 85 230 68,9 71,9 0,9472 - 105 54,6 57,6 0,6162 90 235 69,6 72,6 0,9620 - 130 58,2 61,2 0,6952 110 255 72,3 75,3 1,0212 10 155 61,8...
  • Page 27 Blades overlaps Act. mechanism side "a" Tab. 4.3.1 Side without act. mechanism "c" Tab. 4.3.1 Act. mechanism side "e" Tab. 4.4.1 Side without act. mechanism "f" Tab. 4.4.1 Act. mechanism side "g" Tab. 4.4.1 Side without act. mechanism "h" Tab. 4.4.1 For the design .60 (with BKN supply and communication device) add to weight of the damper with an actuating mechanism (from the Tab.
  • Page 28 Fire dampers are suitable for installation in arbitrary position in vertical and horizontal passages of fire separating constructions. Damper assembly procedures must be done so as all load transfer from the fire separating constructions to the damper body is absolutely excluded. Back-to-back air-conditioning piping must be hung or supported so as all load transfer from the back-to-back piping to the damper is absolutely excluded.
  • Page 29 Built in edge for Built in edge for installation in construction installation in construction Built in edge isolation Built in edge isolation for installation outside for installation outside construction construction BUILT IN EDGE BUILT IN EDGE The control mechanism has to be protected (covered) against damage and pollution during installation process.
  • Page 30 Examples of fire damper installing The fire damper can be integrated into a solid wall construction made e.g. of normal concrete/ masonry, porous concrete with minimum thickness 100 mm or into solid ceiling construction made e.g. of normal concrete with minimum thickness 110 mm or porous concrete with minimum thickness 125 mm.
  • Page 31 Statement of installations the fire dampers FDMA 90 and their fire resistance Tab. 6.1.1. mortar or gypsum stuffing box, fire protection mastic and cement lime plate Weichschott Fire resistant foam mineral wool mineral wool 43, 57 mortar or gypsum stuffing box, fire protection mastic and...
  • Page 32 ≥ 100 ≥ 50* * Around the perimeter ≥ 100 ≥ 40 POSITION: Fire damper FDMA Solid wall construction Mortar or gypsum Duct...
  • Page 33 ≥ 50 ≥ 40 Used materials - example**: POSITION: Promapyr, Rockwool Steprock HD Fire damper FDMA Promastop - P, K Solid wall construction Promatect - H Mineral stone wool min. density 140 kg/m Fire protection mastic min. thickness 1 mm ** Fire resistant insulation and fire resistant board can be Cement lime plate min.
  • Page 34 ≥ 100 D+60 to 800 max. 1650 D+60 to 800 max. 2050 POSITION: 1 Fire damper FDMA 2 Solid wall construction ≥ 100 3 Fire resistant board 4 Fire stop coating thickness 1 mm Used materials - example*: 3 - Hilti CFS-CT B 1S 140/50...
  • Page 35 **Around the perimeter ≥ 50* ≥ 50* ≥ 25 ≤ 300 ≥ 100 variable*** ≥ 400 ≥ 25 ≥ 100 Screw (min. 4x50) ≤ 300 Screws has to be fixed in wall/ceiling con- struction. (If it is needed use steel bracket) ≥...
  • Page 36 ≥ 50** 150* * min. 110 - Concrete/ min. 125 - Aerated concrete ** Around the perimeter ≥ 40 150* POSITION: Fire damper FDMA Solid ceiling construction Mortar or gypsum Duct...
  • Page 37 ** Around the perimeter ≥ 40 ≥ 50 150* POSITION: Used materials - example**: Fire damper FDMA Solid ceiling construction Promapyr, Rockwool Steprock HD Mineral stone wool min. density 140 kg/m Promastop - P, K Fire protection mastic min. thickness 1 mm Promatect - H Cement lime plate min.
  • Page 38 2050 max. 1650 150* * min. 110 - Concrete/ min. 125 - Aerated concrete POSITION: 1 Fire damper FDMA 2 Solid ceiling construction 3 Fire resistant board 4 Fire stop coating thickness 1 mm 5 Duct Fire resistant insulation and fire resistant board can be...
  • Page 39 ≥ 100 ≥ 150 variable**** ≥ 400 POSITION: Fire damper FDMA Solid ceiling construction Mortar or gypsum Stone wool bound with use of an organic resin with crushed stone as a refrigerant (min. density 300 kg/m ), EIS 90, thickness 60 mm Stone wool with one side stitched wire fencing (min.
  • Page 40 ≥ 100 Installation opening has to be reinforced by profile (UW, CW). Profil is fixed by screws ≥3,5 mm with corresponding length. Distance between screws ≤200 mm. ≥ 40 POSITION: Fire damper FDMA Gypsum plate Fire resistant insulation Mortar or gypsum...
  • Page 41 ≤200 mm. ≥ 50 ≥ 40 POSITION: Used materials - example*: Fire damper FDMA Gypsum plate 3 - Promapyr, Rockwool Steprock HD Solid ceiling construction 4 - Promastop - P, K Mineral stone wool min. density 140 kg/m 5 - Promatect - H Fire protection mastic min.
  • Page 42 Profil is fixed by screws ≥3,5 mm with corresponding length. Distance between screws ≤200 mm. D+60 to 800 max. 2050 POSITION: 1 Fire damper FDMA 2 Gypsum plate ≥ 100 3 Solid ceiling construction 4 Fire resistant board 5 Fire stop coating thickness 1 mm...
  • Page 43 ≤200 mm. The screws must be firmly anchored in the profile of gypsum wall con- ≥ 50 ≥ 40 POSITION: Fire damper FDMA Gypsum plate Fire resistant insulation Mineral stone wool min. density 140 kg/m variable*** ≥ 400 ≥ 100 Fire protection mastic min.
  • Page 44 1.) Insert part A into reinforcement VRM-PM 2.) Set up nut of the part A under correct hole 3.) Lock screw B 4.) It has to be done on each side of VRM-90 NOTICE: For dampers with A ≥ 800 and damper placement outside wall construction is necessary to use reinforcement VRM-PM. 1) Cut the groove for profil U25x40x25 2) Insert profile into groove 3) Fix profile...
  • Page 45 ≥ 50 ≥ 40 ≥ 100 ≥ 50 ≥ 40 ≥ 100 POSITION: Fire damper FDMA Solid wall Fire resistant foam Stucco plaster Used materials - example*: 3 - HILTI CFS-F FX - EIS 60 PROMAFOAM-C - EIS 45 SOUDAL, Soudafoam FR-B1 - EIS 30...
  • Page 46 Distance between screws ≤200 mm. ≥ 50 ≥ 40 ≥ 100 POSITION: Fire damper FDMA Gypsum plate Fire resistant insulation Fire resistant foam Stucco plaster Used materials - example*: 3 - HILTI CFS-F FX - EIS 60...
  • Page 47 ≥ 100 ≥ 40* * Around the perimeter ≥ 100 POSITION: Fire damper FDMA Solid wall Mortar or gypsum Stone wool with fire resistance EI 60, (min. density 66 kg/m ), thickness 80 mm Stone wool with fire resistance EI 60, (min. density 66 kg/m ),...
  • Page 48 ≥ 40* * Around the perimeter ≥ 100 POSITION: Fire damper FDMA Solid wall Stuffing box (mineral stone wool min. density 140 kg/m ) Fire protection mastic min. thickness 1 mm Stone wool with fire resistance EI 60, (min. density 66 kg/m ), thickness 80 mm Stone wool with fire resistance EI 60, (min.
  • Page 49 ≥ 50* ≥ 100 ≥ 40* * Around the perimeter ≥ 100 POSITION: Fire damper FDMA Gypsum plate Fire resistant insulation Mortar or gypsum Stone wool with fire resistance EI 60, (min. density 66 kg/m ), thickness 80 mm Stone wool with fire resistance EI 60, (min. density 66 kg/m ),...
  • Page 50 ≥ 50* ≥ 40* * Around the perimeter ≥ 100 POSITION: Fire damper FDMA Gypsum plate Fire resistant insulation Stuffing box (mineral stone wool min. density 140 kg/m ) Fire protection mastic min. thickness 1 mm Stone wool with fire resistance EI 60, (min. density 66 kg/m ), thickness 80 mm Stone wool with fire resistance EI 60, (min.
  • Page 51 Mounting to the ceiling wall 36,6 Position: 58,0 Threaded rod M8 – M20 Washer Coupling Nut Anchor Hinge plate - min. thickness 10 mm Horizontal installation Fire dampers can be suspended by using threaded rods and a mounting profiles. Load the suspension system depend on weight of the fire damper.
  • Page 52 Fire damper Damping pad Extension piece Threaded rod Mounting rail U - Washer Washer Examples of using materials: Vertical installation Fire dampers can be suspended by using threaded rods and a mounting profiles. Load the suspension system depend on weight of the fire damper. Damper can be suspended from the ceiling construction or supported above the ceiling construc- tion.
  • Page 53 Position: Fire damper Damping pad Extension piece Threaded rod Mounting rail U - Washer Washer Screw connection Mounting profile Mounting bracket Fire-resistant board The examples of using materials:...
  • Page 54 Rectangular fire damper suspension on the wall - horizontal installation Duct between fire damper and fire separating construction can be suspended by using threaded rods and mounting profiles. Load the suspension system depend on weight of the fire damper and duct system. Max.
  • Page 55 Horizontal installation Fire dampers can be suspended by using threaded rods and a mounting profiles. Load the suspension system depend on weight of the fire damper. Damper assembly procedures must be done so as all load transfer from the fire separating construc- tions to the damper body is absolutely excluded.
  • Page 56 Damper must be firmly connected with extension piece by screws or rivets. Position: Fire damper Damping pad Extension piece Threaded rod Mounting rail Washer Screw connection Mounting profile Bolt Screw or rivet Expamples of using materials:...
  • Page 57 Duct between fire damper and fire separating construction can be suspended by using threaded rods and suspension rings . Load the suspension system depend on weight of the fire damper and duct system. Max. length between two suspension systems is 1500 mm. Damper assembly procedures must be done so as all load transfer from the fire separating construc- tions to the damper body is absolutely excluded.
  • Page 58 Pressure loss calculation [Pa] Pressure loss air flow speed in nominal damper section [m.s Air density [kg.m coefficient of local pressure loss for the nominal damper section (see Tab. 9.1.1. and Tab. 9.2.1.) Determination of pressure loss by using diagram = 1,2 kg.m...
  • Page 59 Coefficient of local pressure loss (-) - square dampers 1,849 1,476 1,210 0,983 0,888 0,823 0,703 0,608 0,535 0,478 0,437 1,737 1,385 1,095 0,921 0,862 0,782 0,658 0,569 0,500 0,446 0,407 1,678 1,333 0,995 0,887 0,832 0,754 0,638 0,545 0,479 0,430 0,393 1,613...
  • Page 60 0,418 0,400 0,378 0,369 0,352 0,349 0,343 0,331 0,322 0,304 0,291 0,389 0,373 0,356 0,344 0,332 0,325 0,320 0,309 0,300 0,284 0,271 0,375 0,361 0,342 0,333 0,319 0,313 0,309 0,302 0,292 0,272 0,262 0,362 0,345 0,331 0,321 0,308 0,302 0,297 0,291 0,281 0,263...
  • Page 61 Level of acoustic output corrected with filter A. + 10 log(S) + K [dB(A)] level of acoustic output corrected with filter A [dB] level of acoustic output LW1 related to the 1 m section (see Tab. 12.3.1. and 12.3.2) [m ] duct cross section [DB] correction to the weight filter A (see 12.3.3.)
  • Page 62 11,5 14,7 16,9 20,1 22,3 24,1 27,2 29,4 31,2 32,6 33,8 16,7 22,1 25,3 27,5 30,7 32,9 34,6 37,8 40,0 41,7 43,2 44,4 24,2 29,6 32,8 35,0 38,1 40,4 42,1 45,3 47,5 49,2 50,7 51,9 30,0 35,4 38,6 40,8 44,0 46,2 47,9 51,1...
  • Page 63 Damper bodies are supplied in the standard design made of galvanized plate without any other surface finish. Damper blades are made of fire resistant asbestos free boards made of mineral fibres. Damper controls are made of galvanized materials with no other surface finish. Springs are galvanized.
  • Page 64 Manual operation Without power supply, the damper can be operated manually and fixed in any required position. Release of the locking mechanism can be achieved manually or automatically by applying the supply voltage. Before entering the dampers into operation after assembly and after sequential revisions, checks and functionality tests of all designs including operation of the electrical components must be done.
  • Page 65 If fuses Tf2/Tf3 are initiated ( duct inside temperature ) than is possible change only part ZBAT72 or ZBAT95 (according initiating temperature). Data label is placed on the damper body. MANDÍK, a.s. Hostomice 550 267 24 Hostomice Czech Republic FIRE DAMPER FDMA-S CLASSIFICATION: EI 90 (ve ho i o) S SIZE: DESIGN: SERIAL NUMBER: WEIGHT (kg):...
  • Page 66 Mortar or gypsum EIS 90 Mineral stone wool with mastic and EIS 90 cement lime plate Weichschott EIS 90 Mortar or gypsum EIS 90 Mineral stone wool with mastic and EIS 90 cement lime plate Weichschott EIS 90 Mortar or gypsum EIS 90 Mineral stone wool with mastic and EIS 90...
  • Page 67 Manual and thermal Manual and thermal (ZONE 1, 2) Manual and thermal with a terminal switch („CLOSED“) Manual and thermal with a terminal switch („CLOSED“) (ZONE 1, 2) Manual, thermal and with an electromagnet AC 230 V Manual, thermal and with an electromagnet AC/DC 24 V Manual, thermal and with an electromagnet AC 230 V, with a terminal switch („CLOSED“) Manual, thermal and with an electromagnet AC/DC 24 V, with a terminal switch („CLOSED“) Manual, thermal and with an electromagnet AC 230 V (ZONE 2 )
  • Page 68 MANDÍK, a.s. Dobříšská 550 26724 Hostomice Česká republika Tel.: +420 311 706 706 E-Mail: mandik@mandik.cz www.mandik.com The producer reserves the right for innovations of the product. For actual product information see www.mandik.com...
