Summary of Contents for Mandik FDMB Series
- Page 2 FIRE damper type FDMB, is in all variants classified: acc. EN 13501-3 and tested acc. EN 1366-2 and acc. EN 15650. Installation in a solid wall construction ≥ 100 ≥ 40 Fire damper FDMB Solid wall construction Mortar or gypsum Duct Installation in a solid wall construction ≥...
- Page 3 Installation in a gypsum wall construction ≥ 100 Installation opening perimeter has to be reinforced by standard drywall profiles. ≥ 40 Fire damper FDMB Mortar or gypsum Fire protection plate of mineral wool Gypsum wall construction Duct Installation in a gypsum wall construction ≥...
- Page 4 Installation in a solid ceiling construction 150* Fire damper FDMB Solid ceiling construction Mortar or gypsum Duct * min. 110 - Concrete/ min. 125 - Aerated Concrete Installation in a solid ceiling construction ≥ 40 ≥ 50 150* Fire damper FDMB Solid ceiling construction Stuffing box (mineral stone wool min.
- Page 5 Installation in a solid wall construction ≥ 100 ≥ 50* Fire damper FDMB Solid wall construction Mortar or gypsum Duct * Around the perimeter Installation in a solid wall construction ≥ 100 ≥ 50* Fire damper FDMB ≥ 50* Solid wall construction Stuffing box (mineral stone wool min.
- Page 6 Installation in a gypsum wall construction ≥ 100 Installation opening perimeter has to be reinforced by standard drywall profiles. ≥ 50* Fire damper FDMB Mortar or gypsum Fire protection plate of mineral wool Gypsum wall construction Duct * Around the perimeter Installation in a gypsum wall construction ≥...
- Page 7 Installation in a solid ceiling construction 150* Fire damper FDMB Solid ceiling construction ≥ 50** Mortar or gypsum Duct * min. 110 - Concrete/ min. 125 - Aerated Concrete ** Around the perimeter Installation in a solid ceiling construction ≥ 50** ≥...
- Page 8 ≥ 400 variable ** ≥ 100 ≥ 100 ≥ 400 variable ** ≥ 100 ≥ 40 ≥ 100 150* Fire damper FDMB Solid ceiling construction Mortar or gypsum Gypsum wall construction ≥ 100 Solid wall construction Duct variable ** Fire protection plate of mineral wool Mineral stone wool Fire protection mastic min.
- Page 9 ≥ 400 variable ** ≥ 100 ≥ 100 ≥ 400 variable ** ≥ 100 ≥ 100 ≥ 50*** Fire damper FDMB 150* Solid ceiling construction Mortar or gypsum Gypsum wall construction Solid wall construction Duct ≥ 100 Fire protection plate of mineral wool variable ** Mineral stone wool...
- Page 10 ≥ 100 ≥ 100 ≥ 100 ≥ 100 ≥ 100 ≥ 100 Fire damper FDMB Installation frame Solid wall construction...
- Page 11 ≥ 100 ≥ 100 ≥ 100 ≥ 100 ≥ 100 ≥ 100 Fire damper FDMB Installation frame Gypsum wall construction Fire protection plate of mineral wool...
- Page 12 150* 150* 150* 150* 150* 150* Fire damper FDMB Installation frame Solid ceiling construction * min. 110 - Concrete/ min. 125 - Aerated Concrete...
- Page 13 Notice: For installation outside of fire separating construction has to be used reinforcement VRM- III fixing. (60+X)/2 B-X* (60+X)/2 B-X* B+60 B+60 B+60 B+60 * X=23 (AxB≤500x400) * X=23 (AxB≤500x400) * X=36 (AxB>500x400) * X=36 (AxB>500x400)
- Page 14 1. All fire dampers has to be closed during installation process. 2. The control mechanism has to be protected (covered) against damage and pollution during installation process. 3. Min. gap for installation (installation opening) is 25 mm (circular dimension D + 50 mm or square Ø...
- Page 15 7. The fire damper can be integrated into a solid or gypsum wall construction or into solid ceiling construction. Damper blade has to be inside of construction (labelled BUILD IN EDGE on the damper body). The fire damper can also be integrated outside the wall construction. Duct and the damper part between the wall construction and the damper blade (labelled BUILD IN EDGE on the damper body) must be protected with fire-fighting insulation.
- Page 16 The blade of fire damper exceeds body of fire damper by the value “a” and “c” or “e” and “f”. There has to be enough space in duct for blade rotation. Values "a" and "c" or "e" and "f" has to be respected when projecting related air-conditioning ducts.
- Page 17 S1 S2 <5° <80° N L1 S1 S2 <5° <80° 1(COM) - black wire 2(NC) - gray wire 4(NO) - blue wire AC 230V / 5A This limit switch is possible to connect in following two versions: IP 67 if the arm is moving … connect wire 1+2 if the arm is moving …...
- Page 18 14. Before entering the dampers into operation after their assembly and by sequential checks, the following checks must be carried out for all designs. Visual inspection of proper damper integration, inside damper area, damper blade, contact surfaces and silicon sealing. Inspection hole disassembly: release the covering lid by turning the wing nut and while turning the lid right or left release it from the security belt.
- Page 19 Damper bodies are supplied in the standard design made of galvanized plate without any other surface finish. Damper blades are made of fire resistant asbestos free boards made of mineral fibres. Damper controls are made of galvanized materials with no other surface finish. Springs are galvanized.
- Page 20 MANDÍK, a.s. Dobříšská 550 26724 Hostomice Czech Republic Tel.: +420 311 706 706 E-Mail: mandik@mandik.cz www.mandik.com...
