TPM 164/22
Version 2022-12-20
FDMB
Fire damper
Technical Documentation
Installation, Commissioning, Operation, Maintenance and Service Manual
www.mandik.co.uk
Manufacturer
MANDÍK, a. s. • Dobříšská 550 • 267 24 Hostomice • Czech Republic • Tel.: +420 311 706 742 • E-Mail: mandik@mandik.cz
Authorized representative
MANDIK UK Ltd • 130 Aztec West • Bristol BS32 4UB • United Kingdom • Tel.: +44 117 4526376 • E-Mail: help@mandik.co.uk

Advertisement

Table of Contents
loading

Summary of Contents for Mandik FDMB

  • Page 1 Manufacturer MANDÍK, a. s. • Dobříšská 550 • 267 24 Hostomice • Czech Republic • Tel.: +420 311 706 742 • E-Mail: mandik@mandik.cz Authorized representative MANDIK UK Ltd • 130 Aztec West • Bristol BS32 4UB • United Kingdom • Tel.: +44 117 4526376 • E-Mail: help@mandik.co.uk...
  • Page 2: Table Of Contents

    TPM 164/22 These technical specifications state a row of manufactured sizes and models of fire dampers FDMB. It is valid for production, designing, ordering, delivery, maintenance and operation. CONTENT I. GENERAL.....................................3 Description....................................3 Design.....................................4 Design with mechanical control............................4 Design with actuating mechanism............................6 Communication and control module MDCM........................11...
  • Page 3: General

    Certificate of constancy of performance UKCA No. TBD* & UKNI No. TBD* ■ Certificate of constancy of performance CE No. 1391-CPR-2020/0136 ■ Declaration of Perfomance UKCA & UKNI No. PM/FDMB/02/22/1 ■ Declaration of Perfomance CE No. PM/FDMB/01/22/5 ■ Hygienic assessment of fire dampers - Report No. 1.6/pos/19/19c ■...
  • Page 4: Design

    "CLOSED" and "OPEN". Limit switch detail → see page 5 ■ Limit switch Limit switch “OPEN” “CLOSED” Design .80 Page 4 FDMB - Fire damper Version 2022-12-20...
  • Page 5 Class of protection IP 67 CUT-OFF if the arm is moving … connect wire 1+2 ■ Working temperature -25°C … +120°C SWITCH-ON if the arm is moving … connect wire 1+4 ■ Version 2022-12-20 FDMB - Fire damper Page 5...
  • Page 6: Design With Actuating Mechanism

    The time of displacing the blade from the position "OPEN" ■ to the position "CLOSED" takes maximum 20 sec. Thermoelectrical starting mechanism BAT Actuating mechanism Design .40 and .50 Page 6 FDMB - Fire damper Version 2022-12-20...
  • Page 7 1 m, 2 x 0,75 mm² (BFL 24-T-ST) with 3-pin plug-in connectors - auxiliary switch cable 1 m, 6 x 0,75 mm² (BFL 24-T-ST) with 6-pin plug-in connectors duct outside temperature +72°C Thermal trips duct inside temperature +72°C Version 2022-12-20 FDMB - Fire damper Page 7...
  • Page 8 1 m, 2 x 0,75 mm² (BFN 24-T-ST) with 3-pin plug-in connectors - auxiliary switch cable 1 m, 6 x 0,75 mm² (BFN 24-T-ST) with 6-pin plug-in connectors duct outside temperature +72°C Thermal trips duct inside temperature +72°C Page 8 FDMB - Fire damper Version 2022-12-20...
  • Page 9 1 m, 2 x 0,75 mm² - auxiliary switch cable 1 m, 6 x 0,75 mm² (BF 24-T-ST) with plug-in connectors Tf1: duct outside temperature Duct +72°C Thermal trips Tf2/Tf3: duct intside temperature Duct +72°C Version 2022-12-20 FDMB - Fire damper Page 9...
  • Page 10 Ambient humidity Max. 95% RH, non-condensing Connection supply Cable 1 m, 2 x 0.5 mm², Betaflam cable heatresistant up to 145°C Duct inside temperature 72°C Response temperature thermal fuse Duct outside temperature 72°C Page 10 FDMB - Fire damper Version 2022-12-20...
  • Page 11: Communication And Control Module Mdcm

    FCC. This accessory is only required with MANDIK control systems. ■ Each MDCM has a 230v local spur to power the damper actuator. ■...
  • Page 12: Dimensions

    TPM 164/22 Dimensions FDMB with mechanical control (60+X)/2 B-X* B+60 B+60 * X=14 (A<160 or B<160) * X=23 (AxB≤500x400) * X=36 (AxB>500x400) Damper casing Mechanics Damper blade Inspection hole covering Sensor sticker Hole for camera FDMB with actuating mechanism (60+X)/2...
  • Page 13 X=14 (A<160 or B<160) 16,5 X=23 (AxB≤500x400) X=36 (AxB>500x400) Values "a" and "c" has to be respected when Flanges of dampers are 30 mm wide with oval hole. projecting related air-conditioning ducts. Version 2022-12-20 FDMB - Fire damper Page 13...
  • Page 14: Technical Parameters

    0,0112 12,1 13,3 0,0605 0,0124 12,3 13,5 0,0657 0,0149 12,7 13,9 0,0695 0,0173 12,9 14,1 0,0721 52,5 0,0204 13,6 15,1 0,0785 Sizes listed within the maximum/minimum sizes can be manufactured on request. Page 14 FDMB - Fire damper Version 2022-12-20...
  • Page 15 0,0887 14,4 15,9 0,1170 13,7 15,2 0,0939 14,8 16,3 0,1238 13,9 15,4 0,0974 16,5 0,1284 14,6 16,1 0,1060 15,8 17,3 0,1398 Sizes listed within the maximum/minimum sizes can be manufactured on request. Version 2022-12-20 FDMB - Fire damper Page 15...
  • Page 16 16,6 0,1349 16,8 18,3 0,1785 15,5 0,1428 17,3 18,8 0,1890 15,8 17,3 0,1481 17,6 19,1 0,1959 16,5 0,1612 18,7 20,2 0,2133 Sizes listed within the maximum/minimum sizes can be manufactured on request. Page 16 FDMB - Fire damper Version 2022-12-20...
  • Page 17 0,0400 600 x 21,2 0,2970 11,3 12,5 0,0510 22,8 25,6 0,3194 11,7 12,9 0,0619 24,6 27,4 0,3642 52,5 12,3 13,5 0,0756 Sizes listed within the maximum/minimum sizes can be manufactured on request. Version 2022-12-20 FDMB - Fire damper Page 17...
  • Page 18 17,9 0,1591 20,9 22,4 0,2769 117,5 17,9 19,4 0,1871 21,1 23,9 0,2829 19,2 20,7 0,2185 21,9 24,7 0,3068 20,3 21,8 0,2534 Sizes listed within the maximum/minimum sizes can be manufactured on request. Page 18 FDMB - Fire damper Version 2022-12-20...
  • Page 19 26,8 0,3538 23,2 24,7 0,2967 27,8 0,3837 24,7 26,2 0,3441 14,1 15,3 0,0619 26,1 28,9 0,3915 900 x 14,7 15,9 0,0789 Sizes listed within the maximum/minimum sizes can be manufactured on request. Version 2022-12-20 FDMB - Fire damper Page 19...
  • Page 20: Placement And Assembly

    No other services should pass through the dampers ■ building work opening. For lightweight walls always consult the wall manufac- ■ turer specific guidelines for penetrations sizes and dis- tances. Page 20 FDMB - Fire damper Version 2022-12-20...
  • Page 21 The fire damper can be integrated into a gypsum wall If damper is installed outside a construction it is necessary ■ ■ construction with fire classification EI120 or EI 90. to use reinforcing frame VRM2-B → see page 45 Version 2022-12-20 FDMB - Fire damper Page 21...
  • Page 22: Statement Of Installations

    EI 120 (h i↔o) S In solid ceiling construction Mortar or gypsum EI 90 (v i↔o) S EN Spec British Gypsum shaftwall Ablative Coated Batt 33-34 construction EI 60 (v i↔o) S Page 22 FDMB - Fire damper Version 2022-12-20...
  • Page 23: Installation In Solid Wall Construction

    ≥ 100 FDMB Solid wall construction British gypsum thistle bond 60 (or equivalent can by used) minimum density 670 kg/m³ Fixing profile with threaded rod → see pages 35 to 37 Duct Version 2022-12-20 FDMB - Fire damper Page 23...
  • Page 24 Fire resistant mastic - fill the gap on both sides of the fire separation construction and around the perimeter of penetration and damper body. (e.g. HILTI CFS-S ACR) Fixing profile with threaded rod → see pages 35 to 37 Page 24 FDMB - Fire damper Version 2022-12-20...
  • Page 25: Installation Outside Solid Wall Construction

    ISOVER Protect BSF body. (e.g. HILTI CFS-S ACR) VRM2-B → see page 45 (continued on next page) Fixing profile with threaded rod → see pages 35 to 37 Version 2022-12-20 FDMB - Fire damper Page 25...
  • Page 26 ISOVER Protect BSF body. (e.g. HILTI CFS-S ACR) VRM2-B → see page 45 Fixing profile with threaded rod → see pages 35 to 37 Page 26 FDMB - Fire damper Version 2022-12-20...
  • Page 27: Installation In Gypsum Wall Construction

    ≥ 100 FDMB Gypsum wall construction British gypsum thistle bond 60 (or equivalent can by used) minimum density 670 kg/m³ Fixing profile with threaded rod → see pages 35 to 37 Duct Version 2022-12-20 FDMB - Fire damper Page 27...
  • Page 28 Fire resistant mastic - fill the gap on both sides of the fire separation construction and around the perimeter of penetration and damper body. (e.g. HILTI CFS-S ACR) Fixing profile with threaded rod → see pages 35 to 37 Page 28 FDMB - Fire damper Version 2022-12-20...
  • Page 29 Fire resistant mastic - fill the gap on both sides of the fire separation construction and around the perimeter of penetration and damper body. (e.g. HILTI CFS-S ACR) Fixing profile with threaded rod → see pages 35 to 37 Version 2022-12-20 FDMB - Fire damper Page 29...
  • Page 30: Installation Outside Gypsum Wall Construction

    ISOVER Protect BSF body. (e.g. HILTI CFS-S ACR) VRM2-B → see page 45 (continued on next page) Fixing profile with threaded rod → see pages 35 to 37 Page 30 FDMB - Fire damper Version 2022-12-20...
  • Page 31 ISOVER Protect BSF body. (e.g. HILTI CFS-S ACR) VRM2-B → see page 45 Fixing profile with threaded rod → see pages 35 to 37 Version 2022-12-20 FDMB - Fire damper Page 31...
  • Page 32: Installation In Solid Ceiling Construction

    FDMB Solid ceiling construction British gypsum thistle bond 60 (or equivalent can by used) minimum density 670 kg/m³ Fixing profile with threaded rod → see pages 35 to 37 Duct Page 32 FDMB - Fire damper Version 2022-12-20...
  • Page 33: Shaft Wall

    6000 FireLine EI 90 Gyproc ① 2 x 15 4500 FireLine Gyproc ① 2 x 15 4500 FireLine Gyproc ① 2 x 15 6000 FireLine Gyproc ② 2 x 15 6000 FireLine Version 2022-12-20 FDMB - Fire damper Page 33...
  • Page 34 10 Fire resistant mastic - fill the gap on both sides of the fire separation construction and around the perimeter of penetration and damper body. (e.g. HILTI CFS-S ACR) 11 Fixing profile with threaded rod → see pages 35 to 37 Page 34 FDMB - Fire damper Version 2022-12-20...
  • Page 35: Suspension Systems

    Washer for M8 - M20 Coupling Nut M8 - M20 Anchor Hinge plate - min. thickness 10 mm Concrete screw tested for fire resistance R30-R90, max. Tension up to 0.75 KN (length 35 mm) Version 2022-12-20 FDMB - Fire damper Page 35...
  • Page 36 Bored plate HILTI MQZ-L or equivalent Dimension elements of the suspension system Washer for M8 - M20 ■ acc. to the weight of the damper, → see page 35 Nut M8 - M20 Page 36 FDMB - Fire damper Version 2022-12-20...
  • Page 37: Duct Connection

    TPM 164/22 Duct connection FDMB Connecting air duct Extension piece (if required) Damping pad or breakaway connection as DW 144 Version 2022-12-20 FDMB - Fire damper Page 37...
  • Page 38: Technical Data

    ρ [kg/m air density ξ coefficient of local pressure loss for the nominal damper section → see page 39 Determination of pressure loss by using diagram ρ = 1,2 kg/m Page 38 FDMB - Fire damper Version 2022-12-20...
  • Page 39 – – – 0,602 0,528 0,474 0,434 – – – – – – – – – – 1000 0,585 0,512 0,460 – – – – – – – – – – – Version 2022-12-20 FDMB - Fire damper Page 39...
  • Page 40: Noise Data

    -16,7 -24,1 -33,2 -5,2 -3,9 -4,3 -6,4 -10,1 -15,6 -22,7 -31,5 -5,5 -4,1 -5,9 -9,4 -14,6 -21,5 -5,9 -4,1 -5,6 -8,9 -13,8 -20,4 -28,8 -6,2 -4,3 -3,9 -5,3 -8,4 -13,1 -19,5 -27,6 Page 40 FDMB - Fire damper Version 2022-12-20...
  • Page 41: Material, Finishing

    Any other requirements for the design shall be considered atypical and shall be addressed on an individual basis. IV. INSPECTION, TESTING The appliance is constructed and preset by the manufacturer, its operation is dependent on proper installation and ■ adjustment. Version 2022-12-20 FDMB - Fire damper Page 41...
  • Page 42: Transportation And Storage

    (manually or by stopped, in every position, the actuator will be locked. applying power supply). Unlocking is possible even manually as per instructions on the actuator, or by the activation of the supply voltage. Page 42 FDMB - Fire damper Version 2022-12-20...
  • Page 43 ■ ■ of bricking in. the damper body during opening or closing. Protecting the damper against buckling, above all when there are big sizes of fire dampers! WRONG! Brace with wooden blocks Version 2022-12-20 FDMB - Fire damper Page 43...
  • Page 44 TPM 164/22 Change of mechanical design for the motorised one or vice versa Damper Fusible link Mounting plate Mechanics Sealing cover Actuator Seal plates Temperature sensor Mounting plate cover 10 Sensor sticker Page 44 FDMB - Fire damper Version 2022-12-20...
  • Page 45 M8x50 mm hexagon socket head cap screw DIN 912 with M8/8.4 washer DIN 7349 FDMB Part A of VRM2-B Part B of VRM2-B Hexagon socket head cap screw M8x50 mm DIN 912 Washer M8/8,4 DIN 7349 Glue K-84 PROMAT Version 2022-12-20 FDMB - Fire damper Page 45...
  • Page 46: Entry Into Service And Revisions

    M6. Removing the thermal fuse from the fuse holder of initiation device, checks its correct functionality. ■ The mechanism is identified as M1 to M4, depending on the closing spring strength. ■ Page 46 FDMB - Fire damper Version 2022-12-20...
  • Page 47: Spare Parts

    If fuses Tf2/Tf3 are initiated (duct inside temperature) than it's possible to change only part ZBAT72 → see page 10 ■ Spare parts Spare parts are supplied only on basis of an order. ■ Version 2022-12-20 FDMB - Fire damper Page 47...
  • Page 48: Product Data

    FDMB 800x400/375 - .40 design building size of damper size AxB EXAMPLE: FDMB 800x400/375 - .40 - 800x400-damper size, /375-building size of damper, .40-damper design Dampers design Additional digit Manual and thermal Manual and thermal with a terminal switch („CLOSED“) Manual and thermal with two terminal switches („OPEN“, „CLOSED“)
