• Step4: The currently installed firmware version is shown on the LED
display of the Fanatec
picture on the right hand side:
• Step5: If the wheel center was not yet calibrated 'CAL' will
blink on the LED display of the steering wheel as shown
on the picture on the right hand side:
▪
▪
• Step6: Your CSL Elite Racing Wheel is ready to use. If
the wheel center was previously calibrated, step 5 can
be skipped and the CSL Elite Racing Wheel is ready to use immediately.
If you use a H-pattern shifter the wheel base firmware will request to
calibrate the gears automatically now. Refer to chapter 'Shifter calibration
mode later in this user manual'.

7.3 Tuning Menu

Activate the Tuning Menu by pressing the Tuning Menu button
'Hotkeys' chapter of this user manual). The menu will be shown on the tuning
display of the Fanatec
use the directional stick of the Fanatec
Note: Tuning functions are subject to change and may be altered in future
firmware versions.
7.3.1 S_1 ... S_5 (Setups)
Setups range: S_1 ... S_5
The CSL Elite Racing Wheel provides five different setups to store your adjusted
values independently from each other. To change which setup is active, move
the directional stick of the Fanatec
7.3.2 SEN (Sensitivity)
SEN range: 009 ... 108
The sensitivity defines the steering angle. If SEN is set to 009 the steering
wheel can only be turned 90° (45° to left and 45° to right side direction from cal-
ibrated center position). If SEN is set to 108 the steering wheel can be turned
the mechanical maximum way of 1080° (540° to left and 540° to right side di-
rection from calibrated center position). If SEN is set to OFF/Aut the sensitivity
29
®
Proceed with a manual wheel center calibration as
described in chapter 'Hotkeys' of this manual.
The CSL Elite Racing Wheel is ready to use after
manual wheel center calibration.
steering wheel. To navigate through the Tuning Menu,
®
Aut
steering wheel for a moment as shown on the
steering wheel.
®
Setups default: S_1
steering wheel up or down.
®
SEN default: Aut
(see the
