• Step4: The currently installed firmware version is shown on the LED
display of the Fanatec
picture on the right hand side:
• Step5: If the wheel center was not yet calibrated 'CAL' will
blink on the LED display of the steering wheel as shown
on the picture on the right hand side:
▪
▪
• Step6: Your CSL Elite Racing Wheel is ready to use. If
the wheel center was previously calibrated, step 5 can
be skipped and the CSL Elite Racing Wheel is ready to use immediately.
If you use a H-pattern shifter the wheel base firmware will request to
calibrate the gears automatically now. Refer to chapter 'Shifter calibration
mode later in this user manual'.

7.3 Tuning menu

Activate the tuning menu by pressing the tuning menu button
'Hotkeys' chapter of this user manual). The menu will be shown on the tuning
display of the Fanatec
use the directional stick of the Fanatec
Note: Tuning functions are subject to change and may be altered in future
firmware versions.
7.3.1 S_1 ... S_5 (Setups)
Setups range: S_1 ... S_5
The CSL Elite Racing Wheel provides five different setups to store your adjusted
values independent from each other. To change which setup is active, move the
directional stick of the Fanatec
28
®
Proceed with a manual wheel center calibration as
described in chapter 'Hotkeys' of this manual.
The CSL Elite Racing Wheel is ready to use after
manual wheel center calibration.
steering wheels. To navigate through the tuning menu,
®
steering wheel for a moment as shown on the
steering wheel.
®
Setups default: S_1
steering wheel in the up or down direction.
®
(see the
