6.5.3 SHIFTER2
The SHIFTER2 port is used to connect sequential shifters to the CSL Elite
Racing Wheel (e.g. the ClubSport Shifter SQ in SQ mode or the ClubSport
Static Shifter Paddles.) Note: Sequential shifters connected to this port can
be mapped identically to the shifter paddles at the CSL Elite Steering Wheel
(PS4 version) or any other Fanatec steering wheels by PC* driver settings
TM ®
(see chapter 'PC* driver' of this user manual).
Attention: H-pattern shifters will not work on SHIFTER2 port!
6.5.4 PEDAL
The PEDAL port is used to connect pedals to the CSL Elite Racing Wheel (e.g.
the CSL Elite Pedals and CSL Elite Pedals LC.)
6.5.5 HANDBRAKE
The HANDBRAKE port is used to connect an analogue handbrake device to
the CSL Elite Racing Wheel.
6.5.6 POWER
The POWER connector is used to connect the power supply to the CSL Elite
Racing Wheel.
IMPORTANT: Please use only the power supply and power cord that
came with your CSL Elite Racing Wheel. Replacements may only be
issued from an authorized repair center. See 'Electrical Safety' in Chapter
1 'General' for more details!

6.7 Drilling Template

Please download and print the drilling template for hard-mounting the CSL Elite
Racing Wheel from the download area of our website www.fanatec.com.
*PC compatibility not tested nor endorsed by Sony Interactive Entertainment LLC.
