Summary of Contents for FANATEC DD PRO
- Page 1 Manual For/Pour/Für/Para PS5 , PS4...
- Page 2 Thank you for choosing To get the most out of your GT DD PRO, please read this manual before first use. It contains important health and safety information and should be retained for future reference.
-
Page 3: Table Of Contents
INDEX 1. General ......................... 2. Compatibility ......................3. Package Contents ....................4. Assembly ......................6-14 4.1 Plan Your Setup ................... 4.2 Table Clamp ....................4.3 Hard-Mounting ..................... 4.4 Attaching the Steering Wheel ..............4.5 Pedal Setup ....................11-12 4.6 Connections .................... - Page 4 WARNING! Photosensitive Seizures A small percentage of people may experience a seizure when exposed to certain visual images, including flashing lights or patterns that may appear in video games. Even people who have no history of seizures or epilepsy may have an undiagnosed condition that can cause these “photosensitive epileptic seizures”...
-
Page 5: General
To avoid damage, do not expose your GT DD PRO to sources of heat. • When connecting and / or disconnecting any steering wheel to / from the GT DD PRO, take care of the pins inside the Quick Release. - Page 6 • To understand user behaviour with the GT DD PRO, and to help us improve this and future products, the wheel base continuously logs the number of hours it has been used on the standard power supply and Boost Kit 180. Logged data is product-related, not user-related, and therefore anonymous.
-
Page 7: Compatibility
The wheel base can be used with a wide range of Fanatec peripherals to create a more realistic feeling based on the type of vehicle being simulated and your driving style. It’s up to you! You can obtain them from the Fanatec webshop: Fanatec.com... -
Page 8: Package Contents
PACKAGE CONTENTS 1x QR1 Lite Wheel-Side 1x Gran Turismo DD Pro (Officially 1x Steering Wheel for ® licensed for PS5™ consoles) Gran Turismo DD Pro ® 1x CSL Pedals 1x CSL DD Table Clamp 1x T20 Torx Key... - Page 9 (~ 140 cm) (~ 160 cm) (~ 140 cm) (~ 160 cm) 1x Power Supply 1x Power Cord (Regional) * Sold separately 4x M6x8 mm T-Nut 1x USB Type-A to Type-C Cable 1x RJ12 Cable (~ 290 cm) (~ 200 cm)
-
Page 10: Assembly
ASSEMBLY PLAN YOUR SETUP To get started with using the GT DD PRO, decide on whether you will hard- mount the wheel base and pedals or use the CSL DD Table Clamp, connect your steering wheel via the Quick Release system, then connect the GT... - Page 11 TABLE CLAMP...
- Page 12 5 - 60 mm...
-
Page 13: Hard-Mounting
HARD - MOUNTING 10 mm ATTENTION: for hard-mounting! Only for peripheral mounting such as static shifter paddles or a dash display. Thread length: 10 mm NOTE: Use only good quality bolts when 10 mm hard-mounting. Bolt specifications: M6x(10+X) mm... -
Page 14: Attaching The Steering Wheel
ATTACHING THE STEERING WHEEL... -
Page 15: Pedal Setup
PEDAL SETUP For use on hard floor or carpet surfaces Wheel Base / Load Cell 2.5 mm Hard-Mounting Ø 8 mm 30.85 mm 275 mm... - Page 16 CSL Pedals Drilling Template Wheel Base / Load Cell 22 mm M6x(22+X) mm For detailed information on getting the most out of your CSL Pedals, download the manual from Fanatec.com/manuals.
-
Page 17: Connections
CONNECTIONS... -
Page 18: Recommended Accessories
RECOMMENDED ACCESSORIES Alongside the full catalogue of Fanatec peripherals, the following accessories are also compatible with the GT DD PRO. Check them out by clicking on the hyperlinked product names below or at Fanatec.com. Boost Kit 180 ClubSport Shifter SQ V1.5 ClubSport Static Shifter Paddles ClubSport Handbrake V1.5... -
Page 19: Functions & Features
A Windows PC is required to perform firmware updates. Ensure that the wheel base is in PC mode. See chapter 5.3 “Modes”. The firmware provides the GT DD PRO functionality, steering wheel functionality, defines the compatibility, and handles the communication between the device to PC or console, as well as to other peripheral devices such as shifters and pedals. -
Page 20: Modes
- For use on PC. - Detected as a ClubSport Wheel Base V2.5. For PC Compatibility use on PC when the GT DD PRO is not detected or supported by the game. ** USB update rate up to 250Hz in PlayStation mode ®... -
Page 21: Centre Calibration
CENTRE CALIBRATION It may be necessary to calibrate the centre position manually. This will be indicated by “CAL” flashing on the display of the steering wheel as shown on the right, then proceed with the following steps: Enter Tuning Menu Centre the steering wheel Press button combination Exit Tuning Menu... -
Page 22: Shifter Calibration
SHIFTER CALIBRATION NOTE: The steering wheel has a specific button combination in order to perform a shifter calibration. Shifter calibration can also be performed in the PC driver. After a firmware update has been performed, the wheel base will request the shifter calibration automatically as soon as a non-calibrated H-pattern shifter is connected and detected. -
Page 23: Tuning Menu
TUNING MENU In order to enter the Tuning Menu, press the Tuning Menu button of the connected Fanatec steering wheel. The Tuning Menu will be shown on the display of the connected steering wheel. To navigate through the Tuning Menu, use the D-Pad or FunkySwitch of the connected steering wheel. - Page 24 TUNING MENUS AND PROFILES 5.6.1 Standard Tuning Menu: 1 Auto + 1 Custom setup Core parameters only Advanced Tuning Menu: 1 Auto + 5 Custom setup All parameters Auto Setup: Auto Setup allows games to control tuning parameter values for a force feedback experience as intended by the developer.
- Page 25 Cycle Standard and Advanced Tuning Menu: Pressing and hold the Tuning Menu button on your steering wheel for 4 seconds in order to switch between Standard and Advanced Tuning Menu as illustrated below. Press and hold for an additional 6 seconds in order to reset the Custom Setup profiles to the default values.
- Page 26 OFF, there will be no force feedback effect executed by the GT DD PRO motor. If FF is set to 001, the motor will execute only 1% of the maximum motor power. If FF is set to 100, the motor will execute 100% of the maximum motor power.
- Page 27 FFS ( FORCE FEEDBACK SCALING ) 5.6.4 FFS range: LIN (Linear) / PEA (Peak) FFS default: PEA FF Scaling reduces maximum FFB output by a small amount in order FFS Range Max. Torque to guarantee a consistent output 4 Nm between peaks and holding forces Standard PSU 5 Nm...
- Page 28 NFR ( NATURAL FRICTION ) 5.6.6 NFR range: OFF 001 … 100 NFR default: OFF Natural Friction is used to simulate the mechanical feel of steering components. A higher setting results in more resistance when rotating the steering wheel. This can enhance the feeling of driving vehicles without power steering, or with very wide tyres.
- Page 29 FORCE / SPRING / DAMPER EFFECT 5.6.10 FOR range: OFF 010 … 120 FOR default: 100 SPR range: OFF 010 … 120 SPR default: 100 DPR range: OFF 010 … 120 DPR default: 100 These FFB modifiers allow you to change the FFB signals of a game (only applicable if games support these effects).
- Page 30 010 ... 100 SHO default: 100 The strength of the shock / vibration inside a Fanatec steering wheel and pedal set which features vibration motors can be adjusted from 100% to 0%. These vibration motors can be used directly by the game if supported.
- Page 31 NOTE: Not supported by the included steering wheel. Only available if you are using a Fanatec steering wheel or add-on shifter paddles featuring analogue paddles which do not have a dedicated hardware switch for different analogue paddle modes.
- Page 32 BRF ( BRAKE FORCE ) 5.6.15 CSP V3 / V3i: Lo 001 ... 100 BRF default: 050 CSL E P LCK / CSL P LCK: Lo 010 ... 100 BRF default: 050 Brake Force changes the force needed to reach 100% brake input for load cell brake pedals and is available when a pedal set featuring a load cell brake is connected to a wheel base via RJ12.
-
Page 33: Cleaning
Clean only with a dry or slightly damp microfibre cloth. Using cleaning solutions may damage your GT DD PRO. TROUBLESHOOTING The GT DD PRO must not be modified differently other than explicitly described in this manual. Endor AG expressly prohibits analysis and ®... - Page 34 These must not be bent or damaged. Ensure that you have updated your GT DD After booting on the GT DD PRO, the start-up PRO to the latest firmware version which can calibration is not working properly.
-
Page 35: Video Manual
® ‘GT’ and has additional 8 numbers, for example: GT021000370. The serial number of the: - Gran Turismo DD Pro Wheel Base starts with letters ‘GU’ ® - Steering Wheel for Gran Turismo DD Pro starts with letters ‘GV’ ®... -
Page 36: Product Recycling
Imported and distributed by Endor America LLC 8200 Wilshire Blvd. Suite 200 - Beverly Hills CA 90211 - USA US/CAN: +1 321-655-3524 Email: info.webshop@fanatec.com Website: www.fanatec.com - www.endor.ag... -
Page 37: Warranty
In case of issues apparently related to system software / firmware as well as any other product related issues, Endor recommends checking the FAQ database at fanatec.com/ support/faq to see if your problem can be solved there. - Page 38 E.ON-Allee 3 - 84036 Landshut - Germany EU: 00800 0 FANATEC or +49 (871) 9221 -122 US/CANADA: 011 800 0 FANATEC or +49 (871) 9221 -122 AUSTRALIA: 00800 0 FANATEC or +49 (871) 9221 -122 JAPAN: +81 306 7172 -719 Email: info.webshop@fanatec.com...
