The "Steering Wheel RevLEDs test" button starts a signal flow on the LED bar
on the steering wheel top side and activates them to test proper functionality
of each single LED. This is only available for steering wheels which have Rev-
LEDs, refer to the product description of the used steering wheel. The CSL Elite
Steering Wheel has RevLEDs integrated in the rim centre stripe.
The "Vibration test" button starts a vibration signal to activate the vibration
motors inside the Fanatec
wheels which have vibration motors inside, refer to the product description of
the used steering wheel. Not applicable for the CSL Elite Steering Wheel.
shifter must be calibrated. See chapter 'Hotkeys'
for more details
22
steering wheels. This is only available for steering
®
The "Clutch", "Brake", and "Throttle" indicators show the
current activation and position of these single pedals by a
blue bar moving up and down. Therefore the pedals must be
connected to the CSL Elite Racing Wheel.
Note:
Every pedal lever must be pressed down completely to
auto-calibrate the lever movement distance each time when
power resumes.
The "D-pad" arrows (up, down, left, right) change their col-
our from black to blue when the corresponding direction is
pressed on the attached Fanatec
The "Rotary Encoder" boxes flash blue when turning the
FunkySwitch left or right. Not applicable for the CSL Elite
TM
Steering Wheel.
The "2GS" indicator shows the activation of the 2GS (two
gears shifter, sequential shifter, SQ) with a blue square,
depending on the activated shifting position (up or down).
This can be for example the ClubSport Static Shifter Paddles
or the ClubSport Shifter SQ in sequential mode if these are
not mapped to the steering wheel shifter paddles.
The "H-pattern" indicator shows the activation of the 6GS,
7GS or 8GS (six gears shifter, seven gears shifter or eight
gears shifter) with a blue square, depending on the activated
shifting position. This can be for example the ClubSport
Shifter or ClubSport Shifter SQ. Therefore, the H-pattern
steering wheel.
®
'Shifter calibration mode'
