7.3.8 FEI (Force Effect Intensity)
FEI range: OFF ... 100
This parameter adjusts the intensity of force effects and can make effects more
smooth: OFF is very smooth and low noise while 100 is very sharp and direct.
Tuning this parameter can improve the feeling of the wheel depending on the
game. This can be helpful to reduce the noise level especially for bases assem-
bled to tables or rigs.
7.3.9 BRF (brake force)
BRF range: Lo/Min
Increasing BRF value to Hi/Max means the user needs to press the brake pedal
with maximum force to achieve 100% brake input. Reducing the BRF value to
Lo/Min means the user needs to press the brake with minimum force to achieve
100% brake input.
You can either check the brake signal level on the PC* driver or you can see it
on the RevLEDs of the CSL Elite Racing Wheel and/or the attached steering
wheel (depending on steering wheel type).
NOTE:
set is connected to the PEDAL port of the CSL Elite Racing Wheel. Please
read the description and/or manuals of your pedals to verify if the BRF
feature is supported. For reference, the CSL Elite Pedals LC (i.e. CSL Elite
Pedals with Loadcell Kit) support this feature.
7.4

Revolution Lights (RevLEDs)

The CSL Elite Racing Wheel offers the RevLEDs feature integrated directly into
the wheel base. This RevLEDs are usually mirrored with the RevLEDs of the
steering wheel. Games supporting the steering
wheel RevLEDs by default will also support the
wheel base RevLEDs.
Further, if games make use of it, the RevLEDs of the wheel base can indicate
a different function than the Steering Wheel RevLEDs. Example: Wheel Base
RevLEDs show the fuel level while the steering wheel RevLEDs indicate engine
RPM and help the driver shift up at the best moment.
*PC compatibility not tested nor endorsed by Sony Interactive Entertainment LLC.
32
Hi/Max
The BRF parameter is only available when a supported pedal
FEI default: 050
BRF default: 050
